SUPERLIFT® Round Rope Heavy-Lift Sling with Jacket

Name: SUPERLIFT® Round Rope Heavy-Lift Sling with Jacket
Brand: CLGR®

The Round Rope Heavy-Lift Sling with Jacket, as a new high - performance fiber lifting solution replacing heavy anchor chains and steel wire ropes, stand out for their safety, reliability, high cost - effectiveness, and light weight. They also feature a long service life and flexible operation.

Utilizing innovative continuous winding technology, these slings have a robustly braided outer sheath or fabric cover. With extremely low elongation under load, the sheath can be customized based on environmental and usage requirements to shield the load - bearing core from cuts, punctures, scratches, abrasion, and UV degradation, ensuring a durable lifting solution.

Additionally, the slings boast an exceptionally high strength - to - weight ratio. The braided sheath resists external wear, and the slings remain untwisted under load. Lightweight and easy to handle, they offer excellent cut and abrasion resistance, minimizing damage to painted surfaces or precision equipment. Their structural stability and soft hand feel are also notable advantages.

Applications: Heavy lifting, onshore and offshore installation, subsea installation, renewable energy installation, salvage and rescue.

To Get A Quote >

Overview of SUPERLIFT® Round Rope Heavy-Lift Sling with Jacket

Brand	Braided Jacket	Sleeve Jacket
Brand	CLGR®
Material	Load Bearing Core – HMPE/Dyneema® fiber; Jacket/Sleeve – HMPE or Polyester
Construction	Parallel braided cores with a jacket
Specific Gravity	Depending on construction, 0.97 for the HMPE core and 1.38 for the Polyester jacket.
Water absorption	0%
Maximum working temperature	70℃
Product diagram
Length tolerances	±1% nominal length or less
Typical MBL (mT)	460-6200	460-6200
Typical sling lengths (m)	>6	>2
Abrasion resistance	Excellent	Good
UV resistance	Excellent	Excellent
CUT resistance	Excellent	Excellent
Chemical resistance	Excellent	Excellent

Specifications of SUPERLIFT® Round Rope Heavy-Lift Sling with Jacket

Part No.	Dia. mm	Core Weight kg/m	Minimum Break Load (Grommet) kN	Minimum Break Load (Grommet) mT
CRR-LIFT-72	72	2.32	4538	463.0
CRR-LIFT-76	76	2.64	5174	527.9
CRR-LIFT-94	94	3.89	7619	777.5
CRR-LIFT-94	94	3.89	7619	777.5
CRR-LIFT-100	100	4.40	8615	879.0
CRR-LIFT-110	110	5.46	10694	1091.2
CRR-LIFT-114	114	5.88	11523	1175.8
CRR-LIFT-132	132	7.76	15202	1551.2
CRR-LIFT-142	142	9.23	17592	1788.7
CRR-LIFT-152	152	10.60	18831	1921.5
CRR-LIFT-162	162	12.20	21538	2197.7
CRR-LIFT-174	174	13.93	23639	2412.2
CRR-LIFT-182	182	15.34	26002	2653.3
CRR-LIFT-184	184	15.70	26610	2715.3
CRR-LIFT-200	200	18.76	31729	3237.7
CRR-LIFT-206	206	19.56	33079	3375.4
CRR-LIFT-212	212	20.80	33516	3587.4
CRR-LIFT-216	216	21.65	36576	3732.2
CRR-LIFT-226	226	23.84	38906	3970.0
CRR-LIFT-246	246	28.53	44907	4582.3
CRR-LIFT-258	258	31.03	48822	4981.9
CRR-LIFT-268	268	33.64	52900	5397.9
CRR-LIFT-278	278	36.35	57139	5830.6
CRR-LIFT-288	288	39.16	61541	6279.7

Other sizes are available upon request.

Grommet sling strengths @ D/d ≥3.
