CLGR® Twisted Nylon Polyamide Rope

Name: CLGR® Twisted Nylon Polyamide Rope
Brand: CLGR®

The Twisted Nylon Rope, also known as Polyamide Rope, is plaited with nylon multifilament fiber.

The product is water-absorbent, features high strength, good UV resistance, large elongation, free torque, excellent shock absorption and good wear resistance.

Compared with other chemical fiber ropes, it has better impact resistance, a longer service life, and excellent resistance to chemical corrosion and ultraviolet rays.

In the case of the wet condition, the breaking strength is 10% to 15% lower than it is for a new dry rope.

To Get A Quote >

Overview of CLGR® Twisted Nylon Polyamide Rope

Brand	CLGR®
Material	Nylon (Polyamide)
Specific gravity	1.14g/cm³
Water absorption	Yes
Melting Point	218-258℃
Elongation at Break	19-23%
Abrasion Resistance	Excellent
UV Resistance	Good
Chemical Resistance	Good
Standard	In Compliance with OCMIF MEG4

Specifications CLGR® Twisted Nylon Rope Polyamide Rope

Part No.	Size		Weight		Type I				Type II
					DRY		W E T		DRY		W E T
					ISO MBF *		MEG4 LDBE **		ISO MBF *		MEG4 LDBE **
	Dia.(mm)	Circ.(inch)	g/m	Kg/220m	kN	ton	kN	ton	kN	ton	kN	ton
CRSRNR024	24	3	355	78.1	127	13.0	97	9.9	N/A	N/A	N/A	N/A
CRSRNR028	28	31/2	485	106.7	184	18.8	141	14.4	N/A	N/A	N/A	N/A
CRSRNR032	32	4	630	138.6	235	24.0	180	18.3	N/A	N/A	N/A	N/A
CRSRNR036	36	41/2	830	182.6	296	30.2	226	23.1	N/A	N/A	N/A	N/A
CRSRNR040	40	5	1000	220	350	35.7	268	27.3	463	47.2	354	36.1
CRSRNR044	44	51/2	1210	266.2	417	42.6	319	32.6	560	57.1	428	43.7
CRSRNR045	45	55/8	1248	274.6	437	44.6	334	34.1	584	59.6	447	45.6
CRSRNR048	48	6	1430	314.6	501	51.1	383	39.1	656	66.9	502	51.2
CRSRNR050	50	61/4	1535	337.7	537	54.8	411	41.9	716	73.1	548	55.9
CRSRNR052	52	61/2	1680	369.6	588	60.0	450	45.9	777	79.3	594	60.7
CRSRNR055	55	67/8	1862	409.6	621	63.4	475	48.5	886	90.4	678	69.2
CRSRNR056	56	7	2010	442.2	671	68.4	513	52.3	922	94.1	705	72.0
CRSRNR060	60	71/2	2260	497.2	752	76.7	575	58.7	1032	105.3	789	80.6
CRSRNR064	64	8	2520	554.4	841	85.8	643	65.6	1134	115.7	868	88.5
CRSRNR065	65	81/8	2600	572	867	88.4	663	67.7	1170	119.4	895	91.3
CRSRNR068	68	81/2	2860	629.2	953	97.2	729	74.4	1287	131.3	985	100.5
CRSRNR070	70	83/4	3020	664.4	1000	102.0	765	78.1	1359	138.7	1040	106.1
CRSRNR072	72	9	3300	726	1063	108.4	813	83.0	1485	151.5	1136	115.9
CRSRNR075	75	93/8	3460	761.2	1115	113.8	853	87.0	1557	158.9	1191	121.5
CRSRNR080	80	10	4030	886.6	1322	134.9	1011	103.2	1814	185.1	1388	141.6
CRSRNR085	85	2005/8	4450	979	1473	150.3	1127	115.0	2003	204.4	1532	156.4
CRSRNR088	88	11	4780	1051.6	1582	161.4	1210	123.5	2055	209.7	1572	160.4
CRSRNR090	90	2011/4	4990	1097.8	1652	168.6	1264	129.0	2146	219.0	1642	167.5
CRSRNR095	95	2017/8	5560	1223.2	1841	187.8	1408	143.7	2280	232.7	1744	178.0
CRSRNR096	96	12	5690	1251.8	1890	192.9	1446	147.6	2333	238.1	1785	182.1
CRSRNR100	100	2021/2	6160	1355.2	2034	207.5	1556	158.8	2526	257.8	1932	197.2
CRSRNR104	104	13	6660	1465.2	2131	217.4	1630	166.3	2731	278.7	2089	213.2
CRSRNR112	112	14	7720	1698.4	2488	253.8	1903	194.2	3165	323.0	2421	247.1
CRSRNR120	120	15	8870	1951.4	2779	283.6	2126	216.9	3548	362.0	2714	277.0
