CLGR® HMPE Rope for Fishing/Mooring Ships/Ocean Towing Ropes

Name: CLGR® HMPE Rope for Fishing/Mooring Ships/Ocean Towing Ropes
Brand: CLGR®

CLGR® HMPE Rope, which means High Molecular Weight Polyethylene Rope, also known as Dyneema Rope and UHMWPE Marine Mooring Rope.

This ultra-high strength rope is designed to meet the demand for lightweight yet robust solutions in cost-sensitive environments. Crafted from quality 8/12-strand braided HMPE fibre, it optionally features a protective cover braid for enhanced wear resistance.

Key Features

Ultra-high strength with low elongation: When the diameter is the same, the strength is the same as that of the steel cable, and the elongation at break is close to that of the steel cable.
Lightweight design (low density): With the same breaking strength, the weight per meter of the rope is only 12% of steel cable, 20%-25% of nylon or polyester rope, and 18%-20% of polypropylene rope.
Excellent UV and chemical resistance, plus antioxidant properties.
Superior anti-bending and anti-fatigue performance.
Non-bibulous (non-absorbent) and highly wear-resistant.
Applications: Ideal for navy operations, underwater traction, mooring, and high-performance tug cables—where small diameter, high safety, and efficiency are critical.

To Get A Quote >

Overview of CLGR® HMPE Rope for Fishing/Mooring Ships/Ocean Towing Ropes

Brand	CLGR®
Material	UHMWPE
Density	0.97g/m Floating
Structure	8 strand and 12 strand
Melting Point	144-155℃
Elongation at Break	3%-4%
Abrasion Resistance	Excellent
UV Resistance	Excellent
Chemical Resistance	Excellent
Standard	In Compliance with OCMIF MEG4

Specifications of CLGR® HMPE Rope for Fishing/Mooring Ships/Ocean Towing Ropes

8-STRAND AND 12-STRAND

Part No.	SIZE		WEIGHT		I Type				II Type/III Type
	SIZE		WEIGHT		ISO MBF *		MEG4 LDBF **		ISO MBF *		MEG4 LDBF **
	mm	Circ. inch	g/m	kg /220m	kN	ton	kN	ton	kN	ton	kN	ton
CRSRHMPE6	6	3/4	21	4.6	39	4.0	35	3.6	N/A	N/A	N/A	N/A
CRSRHMPE8	8	1	40	8.8	71	7.3	64	6.5	N/A	N/A	N/A	N/A
CRSRHMPE10	10	1-1/4	61	13.4	106	10.8	95	9.7	N/A	N/A	N/A	N/A
CRSRHMPE12	12	1-1/2	83	18.3	150	15.3	135	13.8	N/A	N/A	N/A	N/A
CRSRHMPE14	14	1-3/4	117	25.7	211	21.5	190	19.4	N/A	N/A	N/A	N/A
CRSRHMPE16	16	2	151	33.2	267	27.2	240	24.5	N/A	N/A	N/A	N/A
CRSRHMPE18	18	2-1/4	184	40.5	322	32.9	290	29.6	N/A	N/A	N/A	N/A
CRSRHMPE20	20	02-1-2	227	49.9	384	39.2	346	35.3	N/A	N/A	N/A	N/A
CRSRHMPE24	24	3	324	71.3	533	54.4	480	49.0	N/A	N/A	N/A	N/A
CRSRHMPE28	28	3-1/2	444	97.7	704	71.9	634	64.7	N/A	N/A	N/A	N/A
CRSRHMPE32	32	4	589	129.6	918	93.7	826	84.3	N/A	N/A	N/A	N/A
CRSRHMPE36	36	4-1/2	720	158.4	1104	112.7	994	101.4	840	85.7	756	77.1
CRSRHMPE40	40	5	880	193.6	1329	135.6	1196	122.0	1027	104.8	924	94.3
CRSRHMPE42	42	05-1-4	979	215.4	1459	148.9	1313	134.0	1142	116.5	1028	104.9
CRSRHMPE44	44	5-1/2	1078	237.2	1589	162.1	1430	145.9	1258	128.3	1132	115.5
CRSRHMPE46	46	5-3/4	1171	257.6	1698	173.2	1528	155.9	1366	139.4	1230	125.5
CRSRHMPE48	48	6	1264	278.1	1807	184.4	1626	165.9	1475	150.5	1327	135.4
CRSRHMPE50	50	6-1/4	1388	305.4	1971	201.1	1774	181.0	1619	165.2	1457	148.7
CRSRHMPE52	52	6-1/2	1512	332.6	2136	217.9	1922	196.1	1764	180.0	1588	162.0
CRSRHMPE54	54	6-3/4	1636	359.9	2300	234.7	2070	211.2	1909	194.8	1718	175.3
CRSRHMPE56	56	7	1760	387.2	2464	251.5	2218	226.3	2053	209.5	1848	188.6
CRSRHMPE58	58	7-1/4	1885	414.7	2622	267.6	2360	240.8	2199	224.4	1979	202.0
CRSRHMPE60	60	7-1/2	2010	442.2	2778	283.4	2500	255.1	2345	239.3	2111	215.4
CRSRHMPE62	62	7-3/4	2135	469.7	2936	299.5	2642	269.6	2491	254.2	2242	228.8
CRSRHMPE64	64	8	2260	497.2	3092	315.5	2783	284.0	2637	269.0	2373	242.1
CRSRHMPE66	66	8-1/4	2423	533.1	3293	336.1	2964	302.4	2827	288.5	2544	259.6
CRSRHMPE68	68	8-1/2	2585	568.7	3496	356.7	3146	321.0	3016	307.7	2714	277.0
CRSRHMPE70	70	8-3/4	2748	604.6	3697	377.2	3327	339.5	3206	327.1	2885	294.4
CRSRHMPE72	72	9	2910	640.2	3898	397.7	3508	358.0	3395	346.4	3056	311.8
CRSRHMPE74	74	9-1/4	3065	674.3	4080	416.3	3672	374.7	3576	364.9	3218	328.4
CRSRHMPE76	76	9-1/2	3220	708.4	4263	435.0	3837	391.5	3757	383.3	3381	345.0
CRSRHMPE78	78	9-3/4	3375	742.5	4444	453.5	4000	408.2	3938	401.8	3544	361.6
CRSRHMPE80	80	10	3530	776.6	4628	472.2	4165	425.0	4118	420.2	3707	378.2
CRSRHMPE82	82	10-1/4	3708	815.8	4837	493.5	4353	444.2	4326	441.4	3893	397.3
CRSRHMPE84	84	10-1/2	3885	854.7	5047	515.0	4542	463.5	4533	462.5	4079	416.3
CRSRHMPE86	86	10-3/4	4063	893.9	5256	536.3	4730	482.7	4740	483.7	4266	435.3
CRSRHMPE88	88	11	4240	932.8	5464	557.6	4918	501.8	4947	504.8	4452	454.3
CRSRHMPE90	90	11-1/4	4430	974.6	5678	579.4	5110	521.4	5168	527.4	4652	474.6
CRSRHMPE92	92	11-1/2	4615	1015.3	5893	601.4	5304	541.2	5384	549.4	4846	494.5
CRSRHMPE94	94	11-3/4	4803	1056.7	6108	623.2	5497	560.9	5604	571.8	5043	514.6
CRSRHMPE96	96	12	4990	1097.8	6322	645.1	5690	580.6	5822	594.0	5240	534.6
CRSRHMPE100	100	12-1/2	5515	1213.3	6997	713.9	6297	642.6	6434	656.5	5791	590.9
CRSRHMPE104	104	13	6040	1328.8	7522	767.6	6770	690.8	7047	719.0	6342	647.1
CRSRHMPE120	120	15	7980	1755.6	9856	1005.7	8870	905.1	9311	950.1	8380	855.1

*MBF: Minimum Breaking Force per ISO2307

*LDBF: Line Design Break Force per OCIMF MEG4 appendix B

●Other sizes are available upon request

Bulk Products Photos of HMPE Rope for Fishing/Mooring Ships/Ocean Towing Ropes

CLGR® Are Expecting Your Inquiry!

We design, manufacture and distribute products and provide services for lifting and material handling applications, the construction metal industry, the trawl industry and the yacht accessories industry.
