POWERBLEND® Braided Rope Mooring Tail - Mooring/Marine Rope

Name: POWERBLEND® Braided Rope Mooring Tail - Mooring/Marine Rope
Brand: CLGR®

Mooring tails offer excellent elasticity which play a key role in the mooring arrangement and system, and thus prevent damage to the primary mooring line, ensuring safer operation. Particularly suitable for use in combination with steel or UHMWPE ropes, they are also easy to splice, UV resistant, rot-proof, and highly abrasion resistant, making them an essential protection for primary mooring lines.

The Tails have two types, including Single Leg Tail and Grommet Type Tail.

Single Leg Tail: Standard 11m tails with 1m one end and 2m other end: adequate for sheltered pier side moorings where little or no wave induced vessel motions occur.

22m tails: to be used at exposed pier side moorings where significant ship motions occur; will typically only be required for breast lines and may not be necessary for spring lines.

Grommet Type Tail: Grommet type tails are used in special applications requiring high strengths. The eyes are formed by lashings (seizing the two rope bodies together to form an eye).

The strength of a Grommet mooring tail is 1.7 times the strength of a single leg (of the same material, construction and size) and its length depends on the customer's requirements.

To Get A Quote >

Overview of Braided Rope Mooring Tail - Mooring/Marine Rope

Brand	CLGR®
Size	64mm, 72mm, 80mm, 88mm, 96mm
Type	Braided Rope
Material	Nylon/Polyester/Mixed
Structures	8 Strand,12 Strand, Double Braids
Tails Type	Single Leg
Tails Type	Grommet
Origin	China

Specifications of Braided Rope Mooring Tail - Mooring/Marine Rope

PRODUCT	SIZE		WEIGHT	MEG4 TDBF		MEG4 TDBF
	DIA. mm	Circ. inch	g/m	SINGLE LEG		GROMMET
	DIA. mm	Circ. inch	g/m	kN	ton	kN	ton
NYLON 8-STRAND	64	8	2520	868	88.5	1301	132.8
	72	9	3300	1136	115.9	1704	173.9
	80	10	4030	1388	141.6	2082	212.4
	88	11	4780	1572	160.4	2358	240.6
	96	12	5690	1785	182.1	2677	273.2
NYLON 12-STRAND	64	8	2520	868	88.5	1301	132.8
	72	9	3300	1136	115.9	1704	173.9
	80	10	4030	1388	141.6	2082	212.4
	88	11	4780	1572	160.4	2358	240.6
	96	12	5690	1785	182.1	2677	273.2
POLYESTER 8-STRAND	64	8	3110	1064	108.5	1596	162.8
	72	9	3930	1344	137.1	2016	205.7
	80	10	4850	1659	169.3	2489	254.0
	88	11	5870	2008	204.9	3012	307.4
	96	12	6990	2202	224.7	3303	337.1
POLYESTER 12-STRAND	64	8	3110	1064	108.5	1596	162.8
	72	9	3930	1344	137.1	2016	205.7
	80	10	4850	1659	169.3	2489	254.0
	88	11	5870	2008	204.9	3012	307.4
	96	12	6990	2202	224.7	3303	337.1
POLYESTER-PP 8-STRAND	64	8	2260	698	71.2	1047	106.8
	72	9	2840	874	89.2	1311	133.8
	80	10	3490	1059	108.1	1589	162.2
	88	11	4200	1280	130.6	1920	195.9
	96	12	5000	1519	155.0	2279	232.5
POLYESTER-PP 12-STRAND	64	8	2260	698	71.2	1047	106.8
	72	9	2840	874	89.2	1311	133.8
	80	10	3490	1059	108.1	1589	162.2
	88	11	4200	1280	130.6	1920	195.9
	96	12	5000	1519	155.0	2279	232.5
