POWERSTEELS® Polypropylene (PP) Combination Rope with Steel Core / Polysteel Rope

Name: POWERSTEELS® Polypropylene (PP) Combination Rope with Steel Core / Polysteel Rope
Brand: CLGR®

The POWERSTEELS® Polysteel Rope, which is a polypropylene (pp) combination rope with steel core, features a twisted structure similar to wire rope, with each steel strand covered by PP fibers. This design gives it high tenacity, excellent abrasion resistance, and very low stretch, while also ensuring excellent corrosion resistance—during water use, the internal steel strands are protected from rust, greatly extending the rope's service life while retaining the strength of steel wire rope. The strength and elongation remain basically the same in both dry and wet states.

Application in mooring rope, hauling rope, fishing, port loading and unloading, ocean-going transportation and many other fields.

To Get A Quote >

Overview of POWERSTEELS® Polypropylene (PP) Combination Rope with Steel Core / Polysteel Rope

Brand	CLGR®
Material	Steel, each steel strand is covered with fiber.
Melting Point	165°C
Elongation at break	4%
UV resistance	Normal
Abrasion resistance	Excellent
Resistance to wear	Good
Chemical resistance	Good
Application:	Fishing: PP/ Nylon with steel wire rope Recreation Facility: Nylon/PET with steel wire rope

Specifications of POWERSTEELS® Polypropylene (PP) Combination Rope with Steel Core / Polysteel Rope

4-Strand Parameter Table, Steel Rope 1*19

Part No.	Diameter(mm）		Weight, KG/220M	Total Breaking Force of Steel Wire, kN
Part No.	PP	Steel	Weight, KG/220M	Total Breaking Force of Steel Wire, kN
CRSRPPSC4S3601	36	6.25	352	190
CRSRPPSC4S3602	36	4.60	275	190
CRSRPPSC4S4001	40	5.60	308	258
CRSRPPSC4S4002	40	6.25	363	258
CRSRPPSC4S4201	42	6.25	385	276
CRSRPPSC4S4202	42	6.25	396	276
CRSRPPSC4S4203	42	6.50	407	276
CRSRPPSC4S4401	44	6.25	396	337
CRSRPPSC4S4402	44	7.00	432	337
CRSRPPSC4S4601	46	6.25	418	360
CRSRPPSC4S4602	46	5.00	374	360
CRSRPPSC4S5001	50	5.60	396	455
CRSRPPSC4S5002	50	6.25	407	455
CRSRPPSC4S5003	50	5.30	451	455
CRSRPPSC4S5201	52	5.30	418	526
CRSRPPSC4S5202	52	5.60	440	526
CRSRPPSC4S5401	54	5.30	440	562

3-Strand，6-Strand Parameter Table, Steel Rope 1*19

Part No.	Diameter(mm)		Weight, KG/220M		Total Breaking Force of Steel Wire(kN)
Part No.	PP	Steel	3 Strand	6 Strand	3 Strand	6 Strand
CRSLS3N6S1X1901201	12	2.0	30	42	21.1	21.1
CRSLS3N6S1X1901202	12	2.5	38	57	21.1	21.1
CRSLS3N6S1X1901401	14	2.0	35	47	22.5	22.5
CRSLS3N6S1X1901402	14	2.8	49	73	22.5	22.5
CRSLS3N6S1X1901601	16	2.5	49	68	32.9	32.9
CRSLS3N6S1X1901602	16	3.0	60	87	32.9	32.9
CRSLS3N6S1X1901801	18	2.5	56	75	35.1	35.1
CRSLS3N6S1X1901802	18	3.0	67	94	35.1	35.1
CRSLS3N6S1X1902001	20	3.0	74	102	47.4	47.4
CRSLS3N6S1X1902002	20	4.0	101	149	47.4	47.4
CRSLS3N6S1X1902201	22	3.0	83	110	50.6	50.6
CRSLS3N6S1X1902202	22	4.0	109	158	50.6	50.6
CRSLS3N6S1X1902401	24	3.5	104	141	64.5	64.5
CRSLS3N6S1X1902402	24	4.0	118	167	64.5	64.5
CRSLS3N6S1X1902601	26	3.5	114	151	68.9	68.9
CRSLS3N6S1X1902602	26	4.0	128	177	68.9	68.9
CRSLS3N6S1X1902801	28	4.0	139	188	84.2	84.2
CRSLS3N6S1X1902802	28	4.0	155	217	84.2	84.2
CRSLS3N6S1X1903001	30	4.0	151	199	90	90
CRSLS3N6S1X1903002	30	4.5	167	228	90	90
CRSLS3N6S1X1903201	32	5.0	197	273	132	132
CRSLS3N6S1X1903202	32	5.5	217	309	132	132
CRSLS3N6S1X1903401	34	5.0	211	287	141	141
CRSLS3N6S1X1903402	34	5.5	231	322	141	141
CRSLS3N6S1X1903601	36	6.0	266	376	190	190
CRSLS3N6S1X1903602	36	6.5	290	418	190	190
CRSLS3N6S1X1903801	38	6.0	281	391	202	202
CRSLS3N6S1X1903802	38	6.5	305	433	202	202
CRSLS3N6S1X1904001	40	7.0	346	495	258	258
CRSLS3N6S1X1904002	40	7.5	374	545	258	258
CRSLS3N6S1X1904201	42	7.0	363	511	276	276
CRSLS3N6S1X1904202	42	7.5	390	561	276	276
CRSLS3N6S1X1904401	44	8.0	437	631	337	337
CRSLS3N6S1X1904402	44	8.5	468	688	337	337
CRSLS3N6S1X1904601	46	8.0	455	649	360	360
CRSLS3N6S1X1904602	46	8.5	486	706	360	360
CRSLS3N6S1X1904801	48	9.0	538	784	426	426
CRSLS3N6S1X1904802	48	9.5	573	847	426	426
CRSLS3N6S1X1905001	50	9.0	558	804	455	455
CRSLS3N6S1X1905002	50	9.5	593	867	455	455
CRSLS3N6S1X1905601	56	10.0	694	997	526	526
CRSLS3N6S1X1905602	56	10.5	733	1067	526	526
CRSLS3N6S1X1906001	60	11.0	740	1044	562	562
CRSLS3N6S1X1906002	60	11.0	779	1114	562	562
CRSLS3N6S1X1906601	66	11.0	895	1263	626	626
CRSLS3N6S1X1906602	66	11.5	938	1340	626	626
CRSLS3N6S1X1907001	70	11.0	950	1317	662	662
CRSLS3N6S1X1907002	70	11.5	993	1394	662	662
CRSLS3N6S1X1907601	76	11.5	1080	1482	726	726
CRSLS3N6S1X1907602	76	12.0	1125	1562	726	726
CRSLS3N6S1X1908001	80	11.5	1143	1544	762	762
CRSLS3N6S1X1908002	80	12.0	1187	1624	762	762

3-Strand, 6-Strand Parameter Table, Steel Rope 1*24

Part No.	Diameter(mm)		Weight(KG/220M）		Total Breaking Force of Steel Wire(kN)
Part No.	PP	Steel	3 Strand	6 Strand	3 Strand	6 Strand
CRSLS3N6S1X2401401	14	2.5	42	60	32.9	32.9
CRSLS3N6S1X2401402	14	2.8	48	70	32.9	32.9
CRSLS3N6S1X2401601	16	2.5	48	66	35.1	35.1
CRSLS3N6S1X2401602	16	3.0	58	83	35.1	35.1
CRSLS3N6S1X2401801	18	3.0	65	90	47.4	47.4
CRSLS3N6S1X2401802	18	3.5	76	111	47.4	47.4
CRSLS3N6S1X2402001	20	3.0	72	98	50.6	50.6
CRSLS3N6S1X2402002	20	3.5	84	119	50.6	50.6
CRSLS3N6S1X2402201	22	3.5	92	127	64.5	64.5
CRSLS3N6S1X2402202	22	4.0	106	151	64.5	64.5
CRSLS3N6S1X2402401	24	3.5	101	136	68.9	68.9
CRSLS3N6S1X2402402	24	4.0	115	160	68.9	68.9
CRSLS3N6S1X2402601	26	4.0	125	170	84.2	84.2
CRSLS3N6S1X2402602	26	4.5	140	198	84.2	84.2
CRSLS3N6S1X2402801	28	4.0	136	181	90	90
CRSLS3N6S1X2402802	28	4.5	151	209	90	90
CRSLS3N6S1X2403001	30	5.0	179	251	132	132
CRSLS3N6S1X2403002	30	5.5	198	284	132	132
CRSLS3N6S1X2403201	32	5.0	192	263	141	141
CRSLS3N6S1X2403202	32	5.5	210	297	141	141
CRSLS3N6S1X2403401	34	6.0	244	347	190	190
CRSLS3N6S1X2403402	34	6.5	267	387	190	190
CRSLS3N6S1X2403601	36	6.0	258	361	202	202
CRSLS3N6S1X2403602	36	6.5	281	401	202	202
CRSLS3N6S1X2403801	38	7.0	319	459	258	258
CRSLS3N6S1X2403802	38	7.5	345	506	258	258
CRSLS3N6S1X2404001	40	7.0	335	475	276	276
CRSLS3N6S1X2404002	40	7.5	361	521	276	276
CRSLS3N6S1X2404201	42	8.0	405	587	337	337
CRSLS3N6S1X2404202	42	8.5	435	640	337	337
CRSLS3N6S1X2404401	44	8.0	422	605	360	360
CRSLS3N6S1X2404402	44	8.5	452	658	360	360
CRSLS3N6S1X2404601	46	9.0	501	732	426	426
CRSLS3N6S1X2404602	46	9.5	534	791	426	426
CRSLS3N6S1X2404801	48	9.0	520	751	455	455
CRSLS3N6S1X2404802	48	9.5	553	810	455	455
CRSLS3N6S1X2405001	50	10.0	607	892	526	526
CRSLS3N6S1X2405002	50	10.5	644	958	526	526
CRSLS3N6S1X2405201	52	10.0	628	913	562	562
CRSLS3N6S1X2405202	52	10.5	664	979	562	562
CRSLS3N6S1X2405601	56	10.0	671	956	580	580
CRSLS3N6S1X2405602	56	10.5	707	1022	580	580
CRSLS3N6S1X2406001	60	10.0	717	1002	598	598
CRSLS3N6S1X2406002	60	10.5	754	1068	598	598
CRSLS3N6S1X2406601	66	11.0	868	1213	626	626
CRSLS3N6S1X2406602	66	11.5	908	1285	626	626
CRSLS3N6S1X2407001	70	11.0	922	1267	662	662
CRSLS3N6S1X2407002	70	11.5	962	1339	662	662
CRSLS3N6S1X2407601	76	11.5	1050	1247	726	726
CRSLS3N6S1X2407602	76	12.0	1092	1502	726	726
CRSLS3N6S1X2408001	80	11.5	1112	1489	762	762
