CLGR® Twisted Braided Rope 3-4-6 Strand

Name: CLGR® Twisted Braided Rope 3-4-6 Strand
Brand: CLGR®

CLGR® Twisted Braided Rope 3-4-6 Strand, available in 3-strand, 4-strand, and 6-strand configurations, this rope is crafted to deliver reliable performance across diverse applications.

All ropes are available in materials like polypropylene, high-tenacity polypropylene, polyester, polyester blends, polyamide (nylon), etc., each tailored to specific needs. Normally made in small sizes, they offer high cost performance, along with the advantages of being flexible and easy to splice—making them versatile for a range of applications where practicality and efficiency are prioritized.

Application in Marine mooring, shipbuilding, deep and shallow sea aquaculture, offshore fishing, mining, water conservancy engineering, industrial hoisting, etc.

To Get A Quote >

Overview of CLGR® Twisted Braided Rope 3-4-6 Strand

Brand	CLGR®
Material	Polyolefin, Polyethylene, Power-mixed, polyamide, PP multifilament, polyester
Type	Twist Rope
Strands	3/4/6
Origin	China

Specifications of CLGR® Twisted Braided Rope 3-4-6 Strand

Size		PP Rope		High-tenacity PP Rope		Polyester Rope		Nylon Rope		PE Rope		High-tenacity Polyester Rope
mm Dia.	Inch Cir.	Weight kg/220m	MBL ton	Weight kg/220m	MBL ton	Weight kg/220m	MBL ton	Weight kg/220m	MBL ton	Weight kg/220m	MBL ton	Weight（kg/220m	MBL ton
4	1/2	1.32	0.21	1.68	0.30	2.00	0.30	2.31	0.32	1.78	0.20	2.60	0.30
6	3/4	3.74	0.60	3.78	0.70	4.70	0.90	4.95	0.75	4.00	0.40	6.00	0.56
8	1	6.60	1.06	6.72	1.30	8.30	1.60	8.80	1.35	7.20	0.70	10.60	1.02
10	1-1/4	9.90	1.56	10.50	1.80	12.40	2.40	13.60	2.08	10.80	1.09	16.70	1.59
12	1-1/2	14.30	2.21	15.12	2.60	17.90	3.40	19.60	3.00	15.80	1.54	24.20	2.27
14	1-3/4	20.00	3.05	20.58	3.60	25.00	4.70	27.00	4.10	21.00	2.09	32.60	3.18
16	2	25.30	3.78	26.88	4.50	31.60	5.90	35.00	5.30	28.00	2.80	43.00	4.10
18	2-1/4	32.50	4.82	34.02	5.70	40.60	7.50	44.00	6.70	35.00	3.50	54.00	5.15
20	2-1/2	40.00	5.80	42.00	6.80	50.00	9.00	54.00	8.30	44.50	4.30	67.00	6.40
22	2-3/4	48.40	6.96	50.82	8.20	60.50	10.70	66.00	10.00	53.00	5.10	81.00	7.60
24	3	57.00	8.13	60.48	9.60	71.30	12.60	78.00	12.00	65.00	6.10	96.00	9.10
26	3-1/4	67.00	9.41	70.98	11.10	83.80	14.60	92.00	14.00	72.00	7.00	113.00	10.70
28	3-1/2	78.00	10.70	82.32	12.60	97.50	16.60	107.00	15.80	86.00	8.20	131.00	12.20
30	3-3/4	89.00	12.20	94.50	14.40	111.30	18.90	122.00	17.80	101.00	9.50	150.00	13.70
32	4	101.00	13.50	107.52	15.90	126.30	20.90	139.00	20.00	115.00	10.70	171.00	15.70
36	4-1/2	129.00	16.90	136.08	19.90	161.30	23.30	176.00	24.90	145.00	13.40	216.00	19.40
40	5	158.00	20.50	168.00	24.20	200.00	26.20	218.00	30.00	173.00	16.30	267.00	24.00
44	5-1/2	194.00	24.60	203.28	29.00	245.00	28.80	264.00	35.80	209.00	19.60	323.00	28.50
48	6	229.00	28.60	241.92	33.70	290.00	32.10	312.00	42.00	253.00	22.80	385.00	33.60
52	6-1/2	268.00	33.10	283.92	39.10	330.00	35.10	365.00	48.80	290.00	26.40	451.00	39.20
56	7	312.40	39.59	329.27	50.50	393.80	62.04	442.20	61.53	345.40	30.51	523.60	48.57
60	7-1/2	358.60	45.41	378.00	58.28	441.10	70.54	497.20	68.95	398.20	34.95	600.60	55.44
64	8	407.00	51.33	430.08	65.20	497.20	79.05	554.40	77.14	451.00	39.39	684.20	62.83
65	8-1/8	420.42	52.96	443.94	67.25	512.60	81.43	572.00	79.59	465.85	40.64	706.20	63.22
70	8-3/4	487.74	61.33	514.92	77.49	591.80	93.81	664.00	91.83	540.09	46.89	817.30	77.78
72	9	514.80	64.59	544.32	81.58	624.80	99.06	726.00	101.65	569.80	49.39	864.60	72.70
75	9-3/8	561.66	70.10	590.94	88.59	677.60	109.63	761.20	102.39	620.95	53.52	937.86	83.52
80	10	6400.20	79.39	671.99	100.38	767.80	120.07	886.60	121.31	706.20	60.41	1067.00	98.48
85	10-5/8	722.70	89.29	758.93	113.77	865.42	135.70	979.00	135.32	798.33	68.00	1205.60	107.92
88	11	772.20	95.20	813.12	121.80	924.00	145.08	1051.60	145.35	853.60	72.55	1291.40	115.00
90	11-1/4	808.50	99.69	850.92	124.42	968.00	151.84	1097.50	151.74	853.60	72.55	1350.80	120.29
95	11-7/8	899.14	111.02	947.94	138.86	1078.00	168.72	1223.20	169.07	997.10	84.29	1507.00	132.81
96	12	915.20	113.27	967.67	142.80	1100.00	172.10	1251.80	173.60	1014.20	85.50	1537.80	135.52
100	12-1/2	997.70	120.92	1050.00	154.35	1194.60	187.11	1355.20	186.69	1100.44	92.80	1667.60	149.28
4	1/2	1.32	0.21	1.68	0.30	2.00	0.30	2.31	0.32	1.78	0.20	2.60	0.30
6	3/4	3.74	0.60	3.78	0.70	4.70	0.90	4.95	0.75	4.00	0.40	6.00	0.56
8	1	6.60	1.06	6.72	1.30	8.30	1.60	8.80	1.35	7.20	0.70	10.60	1.02
10	1-1/4	9.90	1.56	10.50	1.80	12.40	2.40	13.60	2.08	10.80	1.09	16.70	1.59
