CLGR® Grade 80 Eye Bolt DIN580

Name: CLGR® Grade 80 Eye Bolt DIN580
Brand: CLGR®

CLGR® Grade 80 Eye Bolt DIN 580, also known as G80 Eye Screw, G80 Rated Eye Bolt, Grade 80 Lifting Eye Bolt.

Made from superior alloy steel with galvanized finish, manufactured with a standard larger eye.

Eye Bolts DIN580 are generally used as a removable lifting point where a rated female thread or nut can be utilised also can be used as a termination for chain, wire rope and other assembles where required.

We available in thread sizes of M6, M8, M10, M12, M16, M20, M24, M30, M36, M42, M48.

To Get A Quote >

CLGR® Grade 80 Eye Bolt DIN580 China Supplier

CLGR® Grade 80 Eye Bolt DIN580 China Manufacturer

CLGR® Grade 80 Eye Bolt DIN580 China Factory

 

Overview of CLGR® Grade 80 Eye Bolt DIN580

Technical Notes	DIN 580
Material	Superior Alloy Steel
Safety Factor	4: 1
Processing	Drop Forged / Quenched and Tempered
Finish	Powder Coated
Size	M6, M8, M10, M12, M16, M20, M24, M30, M36, M42, M48
Tips	Color Code: Customized according to customers' requirements
Note	Never exceed working load limit

Specifications of CLGR® Grade 80 Eye Bolt DIN580

Part No.	Size (mm)	W.L.L (t) (4:1)		D (mm)	K (mm)	N (mm)	L (mm)	Weight (kg/pc)
Part No.	Size (mm)	WLL 0°	WLL 90°	D (mm)	K (mm)	N (mm)	L (mm)	Weight (kg/pc)
8-CR-EB-06	M6	0.4	0.15	28	13	16	42	0.05
8-CR-EB-08	M8	1	0.4	36	15	20	51	0.06
8-CR-EB-10	M10	1	0.4	45	18	25	63	0.11
8-CR-EB-12	M12	2	0.75	54	22	30	75	0.18
8-CR-EB-16	M16	4	1.5	63	28	35	88	0.28
8-CR-EB-20	M20	6	2.3	72	30	40	101	0.45
8-CR-EB-24	M24	8	3.2	90	38	50	128	0.87
8-CR-EB-30	M30	12	4.5	108	45	60	154	1.66
8-CR-EB-36	M36	16	7	126	55	70	183	2.65
8-CR-EB-42	M42	24	9	144	65	80	212	4.03
