CLGR® Galvanized Carabiner Snap Hook with Eye and Screw Nut DIN5299, also known as Carbine hook with eyelet and lock screw or spring snap hook, for quick connection and release of ropes, chains and loops.
This carabine marine snap hook with eye and screw nut is using low carbon steel, as per international qualitative standards DIN5299. Durable and versatile snap hook DIN5299 for attaching ropes, chains, and straps. The marine snap hook is available in various sizes, such as 5mm, 6mm, 7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, with custom sizing also offered by CLGR®, a professional snap hooks manufacturer.
Attention: The CLGR® marine snap hook cannot be opened when loaded with specified load capacity due to elastic deformation.
Brand | CLGR® |
Type | DIN 5299E |
Size | 5x50mm, 6x60mm, 7x70mm, 8x80mm, 9x90mm, 10x100mm, 11x120mm, 12x140mm, 13x160mm spring snap hook with eyelet and screw nut |
Material | Low Carbon Steel |
Processing | Stamping / Machining |
Finish | Zinc Plated (Electro-galvanized) |
Tips | Not for overhead lifting |
Packing | Cartons and then on Pallets (customization are available) |
Part No. | Size | A | B | C | D | L | W.L.L | N.W. |
DIN 5299E | mm | lbs | kgs/100pcs | |||||
CRCSHSNE05 | 5×50 | 25 | 5 | 6 | 5 | 50 | 150 | 2.1 |
CRCSHSNE06 | 6×60 | 30 | 5 | 7 | 6 | 60 | 250 | 3.22 |
CRCSHSNE07 | 7×70 | 35 | 7 | 7.5 | 7 | 70 | 320 | 5.04 |
CRCSHSNE08 | 8×80 | 40 | 10 | 8.5 | 8 | 80 | 400 | 7.7 |
CRCSHSNE09 | 9×90 | 45 | 10 | 9 | 9 | 90 | 500 | 9.9 |
CRCSHSNE10 | 10×100 | 50 | 13 | 10 | 10 | 100 | 650 | 16.2 |
CRCSHSNE11 | 11×120 | 57 | 13 | 16 | 11 | 120 | 700 | 22 |
CRCSHSNE12 | 12×140 | 67 | 15 | 18 | 12 | 140 | 800 | 28 |
CRCSHSNE13 | 13×160 | 74 | 17 | 25 | 13 | 160 | 1200 | 37 |
In addition to above options, we also offer stainless steel carabiner snap hooks for enhanced strength and corrosion resistance. Perfect for marine, industrial, or outdoor use, these rust-proof hooks ensure long-lasting performance even in harsh conditions.
