CLGR® Grade 80 Viking G Hook High Tensile Steel EAG Type

Name: CLGR® Grade 80 Viking G Hook High Tensile Steel EAG Type
Brand: CLGR®

Grade 80 Viking G Hook EAG High Tensile Steel, forged from superior alloy steel, offering high strength and high toughness.

And This G80 Viking G Hook EAG can be used with Viking Master Link Recessed Link EVM.

To ensure top quality, each batch of products undergoes rigorous sampling and breakage testing. Additionally, 100% magnetic particle inspection is carried out to detect any surface or near-surface defects. This ensures every product meets the highest safety and reliability standards.

We are a highly professional Chinese manufacturer and supplier of rigging products. If you are interested, please feel free to contact us.

To Get A Quote >

clgr grade 80 viking g hook eag high tensile steel manufacturers__

CLGR® Grade 80 Viking G Hook High Tensile Steel EAG Type in China

CLGR® Grade 80 Viking G Hook High Tensile Steel EAG Type China

CLGR® Grade 80 Viking G Hook High Tensile Steel EAG Type Odm

CLGR® Grade 80 Viking G Hook High Tensile Steel EAG Type Oem

 

Overview of CLGR® Grade 80 Viking G Hook High Tensile Steel EAG Type

Brand	CLGR®
WLL	4.2T, 6.4T
Material	Superior Alloy Steel
Safety Factor	5: 1
Processing	Drop Forged / Heat Treatment
Surface Finish	Powder Coating
Note	Special specifications and marks can be made according to customer requirements.

Specifications of CLGR® Grade 80 Viking G Hook High Tensile Steel EAG Type

Specifications-CLGR®-Grade-80-Viking-G-Hook-High-Tensile-Steel- EAG

Part No.	WLL 5:1	B.L.	Φ±1	B±1.5	C±1	E±0.5	L±2	Weight
Part No.	ton	Ton	mm					kg
CREAG04	4.2	21	27.5	80	20	15.3	126.5	0.8
CREAG06	6.4	32	31	105.5	33	20	179	2.6

Bulk Photos of Grade 80 Viking G Hook High Tensile Steel EAG Type
