CLGR® Yarding Block Oval Eye Single Sheave

Name: CLGR® Yarding Block Oval Eye Single Sheave
Brand: CLGR®

CLGR® Yarding Block Oval Eye Single Sheave, also known as Snatch Block Yarding Pulley Block.

This yarding block features an oval eye design and a single sheave. It is built for smooth rope handling and heavy-duty pulling tasks.

The material is steel and the surface finish is painted. It is lighter and easy to ship.

The oval eye allows easy attachment to hooks or straps. Designed for smooth rope operation and heavy pulling.

To Get A Quote >

Yarding Block Oval Eye Single Sheave China

Yarding Block Oval Eye Single Sheave China Supplier

Yarding Block Oval Eye Single Sheave China Manufacturer

 

Overview of CLGR® Yarding Block Oval Eye Single Sheave

Brand	CLGR®
Surface Finished	Color Painted
Sheave	Single sheave
Size	3″, 3-1/2'', 4″, 5″, 6″, 8″,10’’
Other Information	Custom sizes and capacities are available at request

Specifications of CLGR® Yarding Block Oval Eye Single Sheave

Drawing of CLGR® Yarding Block Oval Eye Single Sheave China Supplier

No.	Size	W.L.L	Diam of Rope	L	B	A	Net Weight
No.	in	ton	mm	mm	mm	mm	kg
CRYBO03	3″	0.5	6	224	75	88	1.8
CRYBO35	3-1/2’’	1	9	250	87	106	2.1
CRYBO04	4″	1	9	272	90	122	2.45
CRYBO05	5″	1.5	12	335	98	139	3.75
CRYBO06	6″	2	14	382	108	165	6
CRYBO08	8″	4	16	500	130	223	11.5
CRYBO10	10’’	5	16	570	142	294	17.4

CLGR® Are Expecting Your Inquiry!

We design, manufacture and distribute products and provide services for lifting and material handling applications, the construction metal industry, the trawl industry and the yacht accessories industry.
