CLGR® Korean Type Block is built with a forged shackle and reinforced steel side plate, this rope block handles tough jobs with confidence.
The flame-hardened sheave features a recessed groove that reduces rope binding and extends wire rope life. Its half-side design keeps weight low without sacrificing load capacity, while the draw pin allows fast reeving and quick attachment changes—ideal for lifting blocks used in construction, marine, and industrial settings.
Compliant with ASME B30.26-1, this wire rope pulley delivers reliable performance as part of your lifting gear, whether you're redirecting cables or handling daily hoisting tasks.
Available in various sizes and WLL options to suit your needs. The size is is 6 inch, 8 inch and WLL is 5Ton, 7.5 Ton.
Material | Steel |
Surface Finished | Painted or Galvanized |
Size | 6″, 8″, 15″ |
Origin | China |
No. | Size | W.L.L | Dia of Rope | Net Weight |
in | ton | mm | kg | |
CRSK0406 | 6″ | 5 | 20 | 7.7 |
CRSK0408 | 8″ | 7.5 | 28 | 15.8 |
