CLGR® Swivel Hook Flat Block Double Sheave

Name: CLGR® Swivel Hook Flat Block Double Sheave
Brand: CLGR®

CLGR® Swivel Hook Flat Block Double Sheave, also known as Swivel Hook Block, Swivel Pulley With Hook.

A swivel hook pulley block provides added flexibility by rotating as the load is lifted or moved.

Its hook can be attached to various points, including eyelets, rods, bolts, pipes, shackles, or custom mountings.

To Get A Quote >

Overview of CLGR® Swivel Hook Flat Block Double Sheave

Brand	China CLGR®
Sheave	Double Sheave
Craft	Machining/Stamping/Forging/Hot Dipped Galvanized
Material	Stainless Steel
Size	1½”, 2″, 2½”, 3″,3½”, 4″, 5″

Specifications of CLGR® Swivel Hook Flat Block Double Sheave

Part No.	Size	SWL/LBS	Diam	∅	L	A	B	Weight(KG)
CRSHSSB-11	1½”	525	3/16″	38	107	41	19	0.21
CRSHSSB-12	2″	600	3/16″	50	123	54	19	0.31
CRSHSSB-13	2½”	685	1/4″	63.5	143	67	20	0.5
CRSHSSB-14	3″	800	1/4″	75	155	80	41	0.77
CRSHSSB-15	3½”	1550	5/16″	88	214.5	95	43	1.61
CRSHSSB-16	4″	1700	3/8″	100	230.5	108	48	2
CRSHSSB-17	5″	1850	3/8″	125	256	134	58	2.9

CLGR® Are Expecting Your Inquiry!

We design, manufacture and distribute products and provide services for lifting and material handling applications, the construction metal industry, the trawl industry and the yacht accessories industry.
