CLGR® Galvanized Yarding Blocks With Shackle, also known as Snatch Block Yarding Pulley Block, Snatch Block with Bail.
This yarding block features a bail connection for a secure and stable anchor. The toggle pin side plate allows fast rope installation and removal. Steel roller bearings with grease fittings ensure smooth operation and long-lasting durability under load.
This yarding block comes with a shackle for easy rigging.
Brand | CLGR® |
Material | Carbon Steel |
Surface Finished | Spray Painted |
Size | 3″, 4″, 5″, 6″, 8″ |
Other Information | Custom sizes and capacities are available at request |
No. | Size | S.W.L. | Dia of Rope | QTY/Case | N.W./G.W. | WD Size |
(in) | (ton) | (mm) | (pcs) | (kg) | (cm) | |
CRYBWS1101 | 3 | 1.5 | 4~6 | 100 | 168/188 | 113x51x28 |
CRYBWS1102 | 4 | 3 | 6~9 | 50 | 121/141 | 113x36x33 |
CRYBWS1103 | 5 | 4.5 | 8~12 | 50 | 187/207 | 138x41x37 |
CRYBWS1104 | 6 | 6 | 10~14 | 20 | 126/146 | 101x57x28 |
CRYBWS1105 | 8 | 8 | 14~18 | 20 | 276/296 | 145x65x34 |
