CLGR® Round Tab Wire Lock Pin Stainless Steel

Name: CLGR® Round Tab Wire Lock Pin Stainless Steel
Brand: CLGR®

CLGR® Round Tab Wire Lock Pin Stainless Steel, also known as Round Tab Lock Pins, Snapper Pin, and Tab Lock Snapper Pins.

This one-piece fastener combines the function of a pin and cotter pin in a single unit, eliminating the risk of lost or separated parts. Featuring a formed “tab” design, it is even easier to operate than standard wire lock pins.

The tab acts as a load ramp, guiding the wire loop smoothly into the locked position for reliable engagement.

Constructed from durable stainless steel with a mirror-polished finish, this pin offers excellent corrosion resistance and a professional appearance.

To Get A Quote >

Overview of CLGR® Round Tab Wire Lock Pin Stainless Steel

Brand	CLGR®
Material	Stainless Steel AISI304 snapper pin with tab Superior Carbon Steel is also available
Processing	Stamped
Finish	Highly Polished
Size	1/4"×1-3/8", 1/4"×1-3/4", 1/4"×2-1/4", 1/4"×2-1/2", 1/4"×2-1/2" 5/16"×1-3/8", 5/16"×1-3/4", 5/16"×2-1/4", 5/16"×2-1/2", 5/16"×2-1/2" 5/16"×3", 3/8"×1-3/8", 3/8"×1-3/4", 3/8"×2-1/4", 3/8"×2-1/2" 3/8"×2-1/2", 3/8"×3", 1/2"×3"
Tips	Special specification and marks can be made according to customers' requirements
Country of Origin	China

Specification of CLGR® Round Tab Wire Lock Pin Stainless Steel

Part No.	Pin dia	Shank length	Usable length	Wire dia	Wire clearance	Head dia	Handle type	Pcs/bag	Wgt(lbs) /bag
CRSSTWLP010	1/4	1-5/8	1-3/8	0.091	1-5/8	9/16	RD	25	2
CRSSTWLP012	1/4	2	1-3/4	0.091	1-5/8	9/16	RD	25	2
CRSSTWLP014	1/4	2-1/2	2-1/4	0.091	1-5/8	9/16	SQ	25	2
CRSSTWLP015	1/4	2-1/2	2-1/4	0.091	1-5/8	9/16	RD	25	2
CRSSTWLP016	1/4	2-3/4	2-1/2	0.091	1-3/4	9/16	SQ	25	2
CRSSTWLP020	5/16	1-5/8	1-3/8	0.091	1-1/2	5/8	RD	25	2
CRSSTWLP022	5/16	2	1-3/4	0.091	1-1/2	5/8	RD	25	2
CRSSTWLP024	5/16	2-1/2	2-1/4	0.091	1-9/16	5/8	SQ	25	3
CRSSTWLP025	5/16	2-3/4	2-1/2	0.091	1-11/16	5/8	RD	25	3
CRSSTWLP026	5/16	2-3/4	2-1/2	0.091	1-11/16	5/8	SQ	25	3
CRSSTWLP028	5/16	3-1/4	3	0.091	1-11/16	5/8	SQ	25	4
CRSSTWLP030	3/8	1-5/8	1-3/8	0.091	1-1/2	5/8	RD	25	3
CRSSTWLP032	3/8	2	1-3/4	0.091	1-1/2	5/8	RD	25	3
CRSSTWLP034	3/8	2-1/2	2-1/4	0.091	1-1/2	5/8	SQ	25	4
CRSSTWLP035	3/8	2-3/4	2-1/2	0.091	1-5/8	5/8	RD	25	4
CRSSTWLP036	3/8	2-3/4	2-1/2	0.091	1-5/8	5/8	SQ	25	4
CRSSTWLP038	3/8	3-1/4	3	0.091	1-5/8	5/8	SQ	25	3
CRSSTWLP040	1/2	3-1/4	3	0.091	1-5/8	3/4	SQ	25	4
