CLGR® Coil Tension Snap Pin Zinc Plated

Name: CLGR® Coil Tension Snap Pin Zinc Plated
Brand: CLGR®

CLGR® Coil Tension Snap Pin Zinc Plated, also referred to as Snap Pin Wire Lock Pin, Coil Tension Pins, Coiled Tension Safety Pin.

The coil tension snap pins are made from the highest quality clear zinc plated carbon steel, AISI304 stainless steel is also available.

A coil tension snap pin is a threadless fastener for quick equipment changes. Its coiled tab holds it firmly in place, even when parts shift or move.

To Get A Quote >

CLGR® Coil Tension Snap Pin Zinc Plated Main

Overview of CLGR® Coil Tension Snap Pin Zinc Plated

Brand	CLGR®
Material	Super Mild Steel Stainless Steel AISI304 is also available
Processing	Stamped
Finish	Electric Galvanized
Size	1/4" x 1-3/4", 1/4" x 2-1/8", 1/4" x 2-1/2", 1/4" x 3", 1/4" x 4", 5/16" x 2-1/4", 5/16" x 2-3/4", 5/16" x 3", 5/16" x 4", 3/8" x 2-1/4", 3/8" x 2-1/2", 3/8" x 3", 3/8" x 4"
Tips	Special specification and marks can be made according to customers' requirements
Country of Origin	China

Specifications of CLGR® Coil Tension Snap Pin Zinc Plated


Part No.	Pin Dia	Usable Length	Wire Dia	Loop Clearance	Head Dia	Head Height	Pcs/Bag	Wgt(lbs) /Bag
CRSPZP1475	1/4	1 3/4	0.105	1-1/2	1/2	5/16	25	2
CRSPZP1428	1/4	2 1/8	0.105	1-1/2	1/2	5/16	25	2
CRSPZP1425	1/4	2 1/2	0.105	1-1/2	1/2	5/16	25	2
CRSPZP143	1/4	3	0.105	1-1/2	1/2	5/16	25	2
CRSPZP144	1/4	4	0.105	1-1/2	1/2	5/16	25	2
CRSPZP51624	5/16	2 1/4	0.105	1-1/2	1/2	5/16	25	3
CRSPZP51675	5/16	2 3/4	0.105	1-1/2	1/2	5/16	25	3
CRSPZP5163	5/16	3	0.105	1-1/2	1/2	5/16	25	3
CRSPZP5164	5/16	4	0.105	1-1/2	1/2	5/16	25	4
CRSPZP3824	3/8	2 1/4	0.105	1-1/2	5/8	5/16	25	3
CRSPZP3825	3/8	2 1/2	0.105	1-1/2	5/8	5/16	25	3
CRSPZP383	3/8	3	0.105	1-1/2	5/8	5/16	25	4
CRSPZP384	3/8	4	0.105	1-1/2	5/8	5/16	25	5
