CLGR® Coil Tension Snap Pin Stainless Steel

Name: CLGR® Coil Tension Snap Pin Stainless Steel
Brand: CLGR®

CLGR® Coil Tension Snap Pin Stainless Steel, also referred to as Snap Pin Wire Lock Pin, Coil Tension Pins, Coiled Tension Safety Pin.

The coil tension snap pins are made from stainless steel AISI304 for added corrosion protection.

A coil tension snap pin is a threadless fastener for quick equipment changes. Its coiled tab holds it firmly in place, even when parts shift or move.

To Get A Quote >

CLGR® Coil Tension Snap Pin Stainless Steel main

Overview of CLGR® Coil Tension Snap Pin Stainless Steel

Brand	CLGR®
Material	Stainless Steel AISI304 Super Mild Steel is also available
Processing	Stamped
Finish	Highly Polished
Size	1/4" x 3", 1/4" x 4", 5/16" x 3", 5/16" x 4", 3/8" x 3", 3/8" x 4"
Tips	Special specification and marks can be made according to customers' requirements
Country of Origin	China

Specifications of CLGR® Coil Tension Snap Pin Stainless Steel


Part No.	Pin Dia.	Usable Length	Wire Dia	Loop Clearance	Head Dia	Head Height
CRSP143SS	1/4	3	0.105	1-1/2	1/2	5/16
CRSP144SS	1/4	4	0.105	1-1/2	1/2	5/16
CRSP5163SS	5/16	3	0.105	1-1/2	1/2	5/16
CRSP5164SS	5/16	4	0.105	1-1/2	1/2	5/16
CRSP383SS	3/8	3	0.105	1-1/2	5/8	5/16
CRSP384SS	3/8	4	0.105	1-1/2	5/8	5/16
