CLGR® Square Tab Wire Lock Pin Stainless Steel

CLGR® Square Tab Wire Lock Pin Stainless Steel, also known as Square Tab Lock Pins, Snapper Pin, and Tab Lock Snapper Pins.


This one-piece fastener combines the function of a pin and cotter pin in a single unit, eliminating the risk of lost or separated parts. Featuring a formed “tab” design, it is even easier to operate than standard wire lock pins.


The tab acts as a load ramp, guiding the wire loop smoothly into the locked position for reliable engagement.


Constructed from durable stainless steel with a mirror-polished finish, this pin offers excellent corrosion resistance and a professional appearance.

To Get A Quote >
CLGR® Square Tab Wire Lock Pin Stainless Steel
CLGR® Square Tab Wire Lock Pin Stainless Steel

Overview of CLGR® Square Tab Wire Lock Pin Stainless Steel

Brand

CLGR®

Material

Stainless Steel AISI304 tab wire lock pin square type

Superior Carbon Steel is also available

Processing

Stamped

Finish

Highly Polished

Size

1/4"×1-3/8", 1/4"×1-3/4", 1/4"×2-1/4", 1/4"×2-1/2", 1/4"×2-1/2"

5/16"×1-3/8", 5/16"×1-3/4", 5/16"×2-1/4", 5/16"×2-1/2", 5/16"×2-1/2"

5/16"×3", 3/8"×1-3/8", 3/8"×1-3/4", 3/8"×2-1/4", 3/8"×2-1/2"

3/8"×2-1/2", 3/8"×3", 1/2"×3"

Tips

Special specification and marks can be made according to customers' requirements

Country of Origin

China


Specification of CLGR® Square Tab Wire Lock Pin Stainless Steel

Part No.

Pin dia

Shank length

Usable length

Wire dia

Wire clearance

Head dia

Handle type

Pcs/bag

Wgt(lbs)


/bag

CRSSTWLP010

1/4

1-5/8

1-3/8

0.091

1-5/8

9/16

RD

25

2

CRSSTWLP012

1/4

2

1-3/4

0.091

1-5/8

9/16

RD

25

2

CRSSTWLP014

1/4

2-1/2

2-1/4

0.091

1-5/8

9/16

SQ

25

2

CRSSTWLP015

1/4

2-1/2

2-1/4

0.091

1-5/8

9/16

RD

25

2

CRSSTWLP016

1/4

2-3/4

2-1/2

0.091

1-3/4

9/16

SQ

25

2

CRSSTWLP020

5/16

1-5/8

1-3/8

0.091

1-1/2

5/8

RD

25

2

CRSSTWLP022

5/16

2

1-3/4

0.091

1-1/2

5/8

RD

25

2

CRSSTWLP024

5/16

2-1/2

2-1/4

0.091

1-9/16

5/8

SQ

25

3

CRSSTWLP025

5/16

2-3/4

2-1/2

0.091

1-11/16

5/8

RD

25

3

CRSSTWLP026

5/16

2-3/4

2-1/2

0.091

1-11/16

5/8

SQ

25

3

CRSSTWLP028

5/16

3-1/4

3

0.091

1-11/16

5/8

SQ

25

4

CRSSTWLP030

3/8

1-5/8

1-3/8

0.091

1-1/2

5/8

RD

25

3

CRSSTWLP032

3/8

2

1-3/4

0.091

1-1/2

5/8

RD

25

3

CRSSTWLP034

3/8

2-1/2

2-1/4

0.091

1-1/2

5/8

SQ

25

4

CRSSTWLP035

3/8

2-3/4

2-1/2

0.091

1-5/8

5/8

RD

25

4

CRSSTWLP036

3/8

2-3/4

2-1/2

0.091

1-5/8

5/8

SQ

25

4

CRSSTWLP038

3/8

3-1/4

3

0.091

1-5/8

5/8

SQ

25

3

CRSSTWLP040

1/2

3-1/4

3

0.091

1-5/8

3/4

SQ

25

4
