CLGR® Lynch Pin Zinc Plated - The China Supplier

Name: CLGR® Lynch Pin Zinc Plated - The China Supplier
Brand: CLGR®

CLGR® Lynch Pin Zinc Plated, also known as Linch Pins, Linch Locking Fastener, Quick Pins, Click Pins, Linchpins Trailer Quick Release, and Snapper Pins.

They are made from 1010 carbon steel with a Rockwell hardness of 50-60, and surface finished with zinc plated for corrosion protection.

Our linch pins can be great for many uses on boats such as securing linkages.

Steel lanyards or nylon lanyards may be added as a low cost tether to prevent lynch pin loss. These quick locking pins do not require cotter pins and are faster to use than clevis pins and cotters.

Linch pins feature an "over center" Ring loop attached to the head which snaps down hard to hold the fastener in place. Not to be used for overhead lifting.

To Get A Quote >

Overview of CLGR® Lynch Pin Zinc Plated

Brand	CLGR®
Material	Super Carbon Steel
Finish	Electric Galvanized(Yellow Zinc Plated)
Size	3/16″, 1/4″, 5/16″, 7/16″
Tips	Special specification and marks can be made according to customers' requirements
Country of Origin	China

Specification of CLGR® Lynch Pin Zinc Plated

Drawing of CLGR® Lynch Pin Zinc Plated China Supplier

Part No.	(A) Outside Diameter	(E) Effective Length +.079/-.039	(B) Shank Length +.040/-.040″	(H) Inside Diameter
CRLPRZP0875	.188″ (3/16)	.875″ (7/8)	1.125″ (1-1/8)	1.000″ (1)
CRLPRZP1000	.188″ (3/16)	1.000″ (1)	1.250″ (1-1/4)	1.125″ (1-1/8)
CRLPRZP1250	.188″ (3/16)	1.250″ (1-1/4)	1.563″ (1-9/16)	1.406″ (1-13/32)
CRLPRZP1312	.188″ (3/16)	1.313″ (1-5/16)	1.563″ (1-9/16)	1.438″ (1-7/16)
CRLPRZP-250-1250	.250″ (1/4)	1.250″ (1-1/4)	1.563″ (1-9/16)	1.406″ (1-13/32)
CRLPRZP-250-1250A	.250″ (1/4)	1.250″ (1-1/4)	1.750″ (1-3/4)	1.406″ (1-13/32)
CRLPRZP-250-1312	.250″ (1/4)	1.313″ (1-5/16)	1.750″ (1-3/4)	1.438″ (1-7/16)
CRLPRZP-250-1375	.250″ (1/4)	1.375″ (1-3/8)	1.750″ (1-3/4)	1.500″ (1-1/2)
CRLPRZP-250-1500	.250″ (1/4)	1.500″ (1-1/2)	1.750″ (1-3/4)	1.563″ (1-9/16)
CRLPRZP-250-1625	.250“ (1/4)	1.625″ (1-5/8)	1.750″ (1-3/4)	1.688″ (1-11/16)
CRLPRZP-250-1750	.250“ (1/4)	1.750″ (1-3/4)	2.000″ (2)	1.875″ (1-7/8)
CRLPRZP-312-1250	.313″ (5/16)	1.250″ (1-1/4)	1.563″ (1-9/16)	1.406″ (1-13/32)
CRLPRZP-312-1250A	.313″ (5/16)	1.250″ (1-1/4)	1.750″ (1-3/4)	1.406″ (1-13/32)
CRLPRZP-312-1375	.313″ (5/16)	1.375″ (1-3/8)	1.750″ (1-3/4)	1.500″ (1-1/2)
CRLPRZP-312-1500	.313″ (5/16)	1.500″ (1-1/2)	1.750″ (1-3/4)	1.563″ (1-9/16)
CRLPRZP-312-1625	.313″ (5/16)	1.625″ (1-5/8)	2.344″ (2-11/32)	1.875″ (1-7/8)
CRLPRZP-312-1625A	.313″ (5/16)	1.625″ (1-5/8)	2.375″ (2-3/8)	1.875″ (1-7/8)
CRLPRZP-312-1750	.313″ (5/16)	1.750″ (1-3/4)	2.000″ (2)	1.875″ (1-7/8)
CRLPRZP-312-2062	.313″ (5/16)	2.063″ (2-1/16)	2.344″ (2-11/32)	2.188″ (2-3/16)
CRLPRZP-437-1250	.438″ (7/16)	1.250″ (1-1/4)	1.750″ (1-3/4)	1.406″ (1-13/32)
CRLPRZP-437-1343	.438″ (7/16)	1.344″ (1-11/32)	1.563″ (1-9/16)	1.531″ (1-17/32)
CRLPRZP-437-1343A	.438″ (7/16)	1.344″ (1-11/32)	1.969″ (1-31/32)	1.531″ (1-17/32)
CRLPRZP-437-1375	.438″ (7/16)	1.375″ (1-3/8)	1.750″ (1-3/4)	1.500″ (1-1/2)
CRLPRZP-437-1437	.438″ (7/16)	1.438″ (1-7/16)	2.000″ (2)	1.531″ (1-17/32)
CRLPRZP-437-1500	.438″ (7/16)	1.500″ (1-1/2)	2.000″ (2)	1.563″ (1-9/16)
CRLPRZP-437-1500A	.438″ (7/16)	1.500″ (1-1/2)	1.750″ (1-3/4)	1.563″ (1-9/16)
CRLPRZP-437-1500B	.438″ (7/16)	1.500″ (1-1/2)	1.969″ (1-31/32)	1.563″ (1-9/16)
CRLPRZP-437-1625	.438″ (7/16)	1.625″ (1-5/8)	1.938″ (1-15/16)	1.875″ (1-7/8)
CRLPRZP-437-1750	.438″ (7/16)	1.750″ (1-3/4)	2.250″ (2-1/4)	2.000″ (2)
CRLPRZP-437-2250	.438″ (7/16)	2.250″ (2-1/4)	2.500″ (2-1/2)	2.625″ (2-5/8)
