CLGR® Grade 80 Eye Hoist Hook with Latch

Name: CLGR® Grade 80 Eye Hoist Hook with Latch
Brand: CLGR®

CLGR® Grade 80 Eye Hoist Hook with Latch, also known as G80 eye hoist hook with latch, eye cargo hook and g80 eye hook with safety latch, g80 alloy steel eye hoist sling hook with latch.

Certified to U.S. Federal Specification, this forged alloy steel eye hoist hook is quenched and tempered, delivering a 4:1 safety factor for heavy-duty lifting.

Boasting an integrated spring-loaded safety latch to prevent accidental release during dynamic operations, this hook's large eye design allows easy connection to wire rope thimbles for smooth articulation. It offers multiple body finishes, with the latch treated via Dacroment or self-color for superior corrosion resistance.

The large eye of this Alloy Sling Hook for Tow Chains enables easy attachment to most chains and slings. Its secure latch ensures loads stay firmly in place, preventing slips during lifting or pulling operations. The smooth hook design eliminates snags, while the forged construction delivers long-lasting durability.

Designed for versatility, it is ideal as a lifting hook, fixed eye safety hook, winch hoist hook, towing hook, or general-purpose cargo hook in industrial, marine, and construction scenarios.

Available in sizes from 6 to 32, this Grade 80 eye hoist hook combines robust construction with operational security.

Custom finishes, markings, and sizes can be provided to meet specific project requirements.

To Get A Quote >

eye hoist hook with latch alloy steel grade 80 china supplier

eye hoist hook with latch alloy steel grade 80 rigging hook

eye hoist hook with latch alloy steel grade 80 china clgr rigging

eye hoist hook with latch alloy steel grade 80 china for sale

eye hoist hook with latch alloy steel grade 80 china manufacturer

 

Overview of Grade 80 Eye Hoist Hook with Latch

Brand	CLGR®
Standard	US Federal Specification
Type	LG320
Material	Super Alloy Steel
Safety Factor	4: 1
Processing	Body: Forged / Quenched and Tempered. Latch: Forged / Casted / Stamped
Finish	Body: Powder coated Latch: Hot dip galvanized / Galvanized / Dacroment / Stainless steel
Size	6mm, 7/8mm, 10mm, 13mm, 16mm, 20mm, 26mm, 32mm
Tips	Color Code : Customized according to customers' requirements
Note	Use Only Grade 80 Attachments For Overhead Lifting

Specifications of Grade 80 Eye Hoist Hook with Latch

Part No.	WEIGHT (KG)	WLL (T)	B.L (T)	D±1	E±1.5	H±1	K±2	L±2
8CREHHL06	0.28	1.12	4.48	19	22	19	80	110
8CREHHL7/8	0.65	2	8	28	25	25	103	140.5
8CREHHL10	0.94	3.15	12.6	31	27.5	28	118	162
8CREHHL13	1.95	5.3	21.2	39	33	35	145	201
8CREHHL16	3.77	8	32	51	40	45	180	256
8CREHHL20	6.8	12.5	50	62	51	57	230	317
8CREHHL22	9.8	15	60	73	57	70	260	360
8CREHHL26	16.25	21.2	84.8	89	75	76	318	434
8CREHHL32	27.2	31.5	126	90	98	91	360	495.5
