CLGR® Alloy Grade 80 Swivel Safety Hook Dacromet

Name: CLGR® Alloy Grade 80 Swivel Safety Hook Dacromet
Brand: CLGR®

CLGR® Alloy Grade 80 Swivel Safety Hook Dacromet, also called Swivel Self-Locking / Self-Closing hook, Safety cargo hook with swivel and Safety Hook with Swivel Eye.

Conformed to European type EN818-2, forged from special alloy steel for high strength and toughness with subsequent heat treatment, this component is compatible with standard slings and G80 chains.

This swivel hook features a dacromet surface finish, which provides excellent corrosion resistance and gives it a metallic silver appearance, perfectly for tough ocean fishing jobs.

Our swivel safety hook offers reliable 360° horizontal rotation and 180° vertical tilting through its robust swivel mechanism. With a 4:1 safety factor in all directions, it outperforms traditional DIN 580 eyebolts (rigid lifting eyes) in flexibility and load adaptability.

While not featuring ball bearings, its durable construction provides dependable performance for general lifting applications at a more economical price point. It suitable for port and ship operations, construction and heavy lifting.

Available G80 swivel self-locking hook sizes include: 6mm, 7/8mm, 10mm, 13mm, 16mm, 18/20mm, 22mm, 26mm, and 32mm.

To Get A Quote >

clgr® alloy grade 80 swivel safety hook dacromet china supplier main

clgr® alloy grade 80 swivel safety hook dacromet china supplier side 2

clgr® alloy grade 80 swivel safety hook dacromet china

clgr® alloy grade 80 swivel safety hook dacromet china supplier side

 

Overview of CLGR® Alloy Grade 80 Swivel Safety Hook Dacromet

Brand	CLGR®
Size	6mm, 7/8mm, 10mm, 13mm, 16mm, 18/20mm, 22mm, 26mm, 32mm
Standard	European Type
Material	Superior Alloy Steel
Safety Factor	4: 1
Processing	Forged / Heat Treatment
Surface Finish	Dacromet
Important Note	Using with grade 80 alloy chain or wire rope for overhead lifting

Specifications of CLGR® Alloy Grade 80 Swivel Safety Hook Dacromet

drawing-of-clgr®-alloy-grade-80-swivel-safety-hook-dacromet-china-supplier

Part No.	Weight (kg)	W.L.L. (t)	B.L. (t)	A±1	B±1	C±2	D1±2	E±3	F±3
8CRSSHDA6	0.71	1.12	4.48	32.5	24	35	28	152.5	184
8CRSSHDA7/8	1.15	2	8	36	29.5	40	35.8	189	228
8CRSSHDA10	1.86	3.15	12.6	42	35	50	48	224	270
8CRSSHDA13	3.51	5.3	21.2	50	41	60	52.5	267	324
8CRSSHDA16	7.33	8	32	61	56.8	65	63.3	355.6	406
8CRSSHDA18/20	10.3	12.5	50	72	63	80	86	378.2	460.5
8CRSSHDA22	17.5	15	60	97	98	83	76	466	564
8CRSSHDA26	23	21.2	84.8	123	115	106	96	544	661
8CRSSHDA32	81	31.5	126	140	146	140	135	679	892
