CLGR® Trawl Block with Swivel Eye CRT Type

Name: CLGR® Trawl Block with Swivel Eye CRT Type
Brand: CLGR®

CLGR® Trawl Block with Swivel Eye CRT Type, also known as Fishing Trawl Block and Half Sided Trawl Blocks.

CLGR® Trawl Blocks boast work - hardening manganese steel sheaves that maximize the lifespan of both wire ropes and sheaves. They are equipped with tapered roller bearings, ensuring long - term use even in applications with higher line speeds.

An enclosed swivel eye prevents net entanglement, while a recessed sheave stops wire ropes from binding between the sheave and block side.

Galvanized for a durable, corrosion - resistant finish, these blocks feature a half - side design that balances strength and minimized weight, along with rugged cast alloy steel sides to withstand demanding environments.

We have Size from 6″,8″,10″,12″,14″,16″,18″,20″,22″, WLL from 3 Ton to 35 Ton and Rope size from 1 INCH to 4 INCH.

They are usable for offshore, maritime, construction and commercial fishing.

To Get A Quote >

CLGR® Trawl Block with Swivel Eye CRT Type Supplier

Overview of CLGR® Trawl Block with Swivel Eye CRT Type

Brand	CLGR®
Material	Super Carbon Steel
Surface Finished	Hot Dipped Galvanized
Size	6″, 8″, 10″, 12″, 14″, 16″, 18″, 20″, 22″
Origin	China

Specifications of CLGR® Trawl Block with Swivel Eye CRT Type

Part No.	Size (in)	W.L.L (ton)	Dia of Rope (in)	Net Weight (kg)
CRETR06*2.5	6"	3	1 - 2	13
CRETR06*3	6"	5	1 - 2	16
CRETR08*3	8"	10	1 - 2	32
CRETR08*4	8"	10	1 - 2	36.5
CRETR10*4	10"	10	1 - 3	42
CRETR12*4	12"	10	1 - 3	45
CRETR12*5	12"	10	1 - 4	53
CRETR14*4	14"	10	1 - 3	60
CRETR16	16"	20	1 - 4	105
CRETR18	18"	25	1 - 4	146
CRETR20	20"	30	1 - 4	216
CRETR22	22"	35	1 - 4	246
