CLGR® Stainless Steel Anchor Shackle with Screw Pin European Type for Trawling

Name: CLGR® Stainless Steel Anchor Shackle with Screw Pin European Type for Trawling
Brand: CLGR®

CLGR® Stainless Steel Anchor Shackle with Screw Pin, also known as Bow Shackle Screw Pin.

Anchor Shackle with Screw Pin is made of 304 or 316 stainless steels. This material has glossy surface, antirust, anti-corrosion, sturdy and durable to use. As a part of our premium rigging hardware collection, the shackles for sale are designed to work with hooks, ropes, and other rigging components.

CLGR® Bow Shackle with Screw Pin offers a wide range of applications in various industries, from construction to maritime. Anchor Shackle Screw Pin allows for easy attachment and removal, and the bow design supports multi-directional forces.

As one of the leading shackles manufacturers, we offer sizes from 4mm to 36 mm, also can be made according to customers' requirements.

To Get A Quote >

CLGR® Stainless Steel Anchor Shackle with Screw Pin European Type for Trawling

 

Overview of CLGR® Stainless Steel Anchor Shackle with Screw Pin European Type

Brand	CLGR®
Size	4mm, 5mm, 6mm, 8mm, 10mm, 12mm, 14mm, 16mm 18mm, 20mm, 22mm, 25mm, 28mm, 32mm, 36mm
Standard	European Type
Material	Stainless Steel grade 304 or 316
Surface Finish	Highly Polishing, Electrophoretic Coating
Processing	Forged, Stamping
Important Note	Not suitable for lifting applications

Specification of CLGR® Stainless Steel Anchor Shackle with Screw Pin European Type

drawing-stainless-steel-anchor-shackle-screw-pin-european-type for Trawling

Part No.	SIZE	A	B	C	D	E	MBL
Part No.	SIZE	mm					KN
CR-SS-BS-EU-04	4	16	8	8	4	14	5.8
CR-SS-BS-EU-05	5	19	10	10	5	16	9.1
CR-SS-BS-EU-06	6	25	12	12	6	20	13.2
CR-SS-BS-EU-08	8	32	16	16	8	24	23.7
CR-SS-BS-EU-10	10	38	20	20	10	28	37.3
CR-SS-BS-EU-12	12	48	24	24	12	36	54.9
CR-SS-BS-EU-14	14	50	28	28	14	38	74.8
CR-SS-BS-EU-16	16	55	32	32	16	10	97.7
CR-SS-BS-EU-18	18	62	36	36	18	43	136.1
CR-SS-BS-EU-20	20	68	40	40	20	46	184.7
CR-SS-BS-EU-22	22	82	44	44	22	56	223.8
CR-SS-BS-EU-25	25	95	50	50	25	68	-
CR-SS-BS-EU-28	28	108	56	56	28	74	-
CR-SS-BS-EU-32	32	120	64	64	32	84	-
CR-SS-BS-EU-36	36	135	72	72	36	92	-
