CLGR® Grade 80 Master Link Assembly European Type EN1677-4 / DIN5688-3

Name: CLGR® Grade 80 Master Link Assembly European Type EN1677-4 / DIN5688-3
Brand: CLGR®

Grade 80 Master Link Assembly European Type, also called Master Links with Sublinks G80, Oblong Master Link Sub-Assembly, Grade 80 Quad Master Link Assembly, Grade 80 Large Multi Headring and Welded Master Link Assembly.

The Master Link Assembly are primarily used for rigging assembly. The master-sub link assembly connects chain connectors and chain links to form composite sling systems, designed for lifting heavy loads and equipment.

This assembly features a fully forged master ring integrated with two or more welded sub-rings, constructed from high-grade alloy steel. Available in sizes ranging from 6-32mm (customized sharps and sizes also), it maintains a safety factor of 4:1 to ensure reliable performance under heavy loads.

To Get A Quote >

CLGR® Grade 80 Master Link Assembly European Type Manufacturers

CLGR® Grade 80 Master Link Assembly European Type Suppliers

CLGR® Grade 80 Master Link Assembly European Type Wholesale Manufacturers

CLGR® Grade 80 Master Link Assembly European Type Wholesale Suppliers

CLGR® Grade 80 Master Link Assembly European Type Factory

CLGR® Grade 80 Master Link Assembly European Type Exporter

CLGR® Grade 80 Master Link Assembly European Type China

 

Overview of CLGR® Grade 80 Master Link Assembly European Type EN1677-4 / DIN5688-3

Brand	CLGR®
Size	6mm, 7mm, 8mm, 10mm, 13mm, 16mm, 18mm, 20mm, 22mm, 26mm, 28mm, 32mm
Material	Super Alloy Steel
Standard	European Type (EN1677-4 / DIN5688-3)
Safety Factor	4: 1
Processing	8-CR-MLA-1677-6 to 8-CR-MLA-1677-20 ⇒ Main link: WELDED; Sub links: WELDED, flat on request. 8-CR-MLA-1677-22 to 8-CR-MLA-1677-32 ⇒ Main link: FORGED; Sub links: WELDED, no pressing flat. Quenched and Tempered
Surface Finish	Powder Coated
Note	Never Exceed Rated Capacity; Color code can be customized

Specifications of CLGR® Grade 80 Master Link Assembly European Type EN1677-4 / DIN5688-3

Drawing Grade 80 Master Link Assembly European Type EN1677-4 / DIN5688-3

Part NO.	G80 EN818-2 CHAIN	WEIGHT	WLL	DIMENSION(MM)
Part NO.	FOR 3 OR 4 LEG SLING	(KG)	(T)	A	B	D	a	b	d
8-CR-MLA-1677-06	6	1.18	2.36	135	75	18	54	25	13
8-CR-MLA-1677-07	7	1.24	3.15	135	75	18	50	38	13
8-CR-MLA-1677-08	8	2.2	4.25	160	90	22	70	34	16
8-CR-MLA-1677-10	10	3.4	6.7	180	100	26	85	40	18
8-CR-MLA-1677-13	13	6.1	11.2	200	110	32	115	50	22
8-CR-MLA-1677-16	16	9.98	17	260	140	36	140	65	26
8-CR-MLA-1677-18	18	18.9	21.2	340	180	45	180	100	32
8-CR-MLA-1677-20	20	22.6	26.5	350	190	50	180	100	32
8-CR-MLA-1677-22	22	25.2	31.5	350	190	50	180	100	36
8-CR-MLA-1677-26	26	35.2	45	400	200	56	180	100	40
8-CR-MLA-1677-28	28	47	50	130	220	63	180	100	45
8-CR-MLA-1677-32	32	66.46	63	460	250	72	200	110	50
