CLGR® Grade 100 Chain Connectors European Type

Name: CLGR® Grade 100 Chain Connectors European Type
Brand: CLGR®

Grade 100 Chain Connectors, also referred to as G100 Coupling Links, G100 hammerlock connecting link and G100 Lifting Component Connectors.

The CLGR® G100 Chain Connectors are commonly used to connect Head Rings, Chain, Hooks and other lifting components.

Crafted from high-quality alloy steel with a painted surface finish, the G100 Chain Connectors are specifically designed for the fishing and trawl industries, offering exceptional strength and corrosion resistance.

The G100 Chain Connectors come equipped with a spare pin and a single steel bush.

Known as a hammerlock, this trawl component connector is manufactured under strict quality control standards, combining high strength, lightweight design, and durability for easy and safe handling.

The available sizes of G100 hammerlock chains range from 6mm to 32mm.

To Get A Quote >

CLGR® Grade 100 Chain Connectors European Type Manufacturers

CLGR® Grade 100 Chain Connectors European Type Suppliers

CLGR® Grade 100 Chain Connectors European Type Factory

CLGR® Grade 100 Chain Connectors European Type Exporter

CLGR® Grade 100 Chain Connectors European Type China

CLGR® Grade 100 Chain Connectors European Type in China

 

Overview of CLGR® Grade 100 Chain Connectors European Type

Brand	CLGR®
Size of Rope	6mm, 8mm, 10mm, 13mm, 16mm, 20mm, 22mm, 26mm, 32mm
Standard	European Type
Material	Superior Alloy Steel
Safety Factor	4: 1
Processing	Drop Forged + Quenched and Tempered Pressing flat only on request
Surface Finish	Powder Coating
Note	Color Code: Customized according to customers' requirements

Specifications of CLGR® Grade 100 Chain Connectors European Type

Drawing CLGR® Grade 100 Chain Connectors European Type

Part No.	Weight (kg)	WLL (t)	B.L. (t)	H±1	A±1.5	K±2	L±2.5
10CRCL06	0.08	1.4	5.6	7.6	14	44.5	60
10CRCL08	0.18	2.5	10	10	18.5	61.5	84.5
10CRCL10	0.34	4	16	12.6	23	72	97.2
10CRCL13	0.68	6.7	26.8	16.8	27.5	89	127
10CRCL16	1.22	10	40	21	33.5	103	145
10CRCL20	2.13	16	64	24.5	42	116	175
10CRCL22	3	19	76	27	48	135	193
10CRCL26	5.15	26.5	106	32	61	164	228
10CRCL32	9.5	39.3	157.2	40	80	194	274

Bulk Photos of CLGR® Grade 100 Chain Connectors European Type
