The 5 Tonne/5000kg Red Polyester Endless Round Sling CLGR®, also referred to as round textile sling, or Endless Polyester Round Lifting Sling, some customers also called it Red Lifting Sling Round and Round Webbing Sling.
WLL 5tonne round slings designed specifically for lifting applications. These slings provide dimensional stability with excellent flexibility, instantly contouring to the load for secure and balanced lifting. They are ideal for handling highly polished surfaces and are available in various colors to indicate load ratings.
The Red round lifting sling 5 Ton capacity is made of 100% polyester and conform to EN1492. Each sling is proof-tested, serial-numbered, and comes with a test certificate. A color-coded outer cover with woven-in weight markings ensures easy identification in daily use.
The Polyester Endless Round Slings offer excellent UV, rot, mildew resistance, and no strength loss in water. Lightweight and easy to handle, they protect workers' hands and resist acids but are not suitable for heavy alkalis.
Brand | CLGR® |
Standard | EN 1492 |
Color | Red |
Material | 100% high tenacity polyester of our sleeve and inner core |
WLL | 5ton / 5000kg Working Load Limit (WLL) |
Safety factor | 5:1, 6:1, 7:1, 8:1 |
Effective working length | 1m to 20m |
Part No. | Colour | Length | W.L.L. | Weight |
m | TON | Kg | ||
CRRS5T01 | Red | 1 | 5 | 1 |
CRRS5T02 | 2 | 5 | 2.05 | |
CRRS5T03 | 3 | 5 | 3.05 | |
CRRS5T04 | 4 | 5 | 3.95 | |
CRRS5T05 | 5 | 5 | 5 | |
CRRS5T06 | 6 | 5 | 5.95 | |
CRRS5T08 | 8 | 5 | 7.9 | |
CRRS5T010 | 10 | 5 | 9.75 |
All slings are color-coded to indicate WLL (Working Load Limit).
Colour | Colour coded according to EN1492-2 | Working load limit with 1 webbing sling | Working load limit with 2 webbing sling | Working load limit with 2 webbing sling - Choked lift up to 45-60° | |||||||||
Straight lift | Choked lift | β | Straight lift up to 45° | Choked lift up to 45° | Straight lift up to 45-60° | ||||||||
0°-7° | 7°-45° | 45°-60° | up to 45° | 45°-60° | |||||||||
 |
|  |
|  |
|  |  |  | | ||||
Violet | WLL 1T | 1,000 | 800 | 2,000 | 1,400 | 1,000 | 700 | 500 | 1,400 | 1,120 | 1,000 | 800 | |
Green | WLL 2T | 2,000 | 1,600 | 4,000 | 2,800 | 2,000 | 1,400 | 1,000 | 2,800 | 2,240 | 2,000 | 1,600 | |
Yellow | WLL 3T | 3,000 | 2,400 | 6,000 | 4,200 | 3,000 | 2,100 | 1,500 | 4,200 | 3,360 | 3,000 | 2,400 | |
Gray | WLL 4T | 4,000 | 3,200 | 8,000 | 5,600 | 4,000 | 2,800 | 2,000 | 5,600 | 4,480 | 4,000 | 3,200 | |
Red | WLL 5T | 5,000 | 4,000 | 10,000 | 7,000 | 5,000 | 3,500 | 2,500 | 7,000 | 5,600 | 5,000 | 4,000 | |
Brown | WLL 6T | 6,000 | 4,800 | 12,000 | 8,400 | 6,000 | 4,200 | 3,000 | 8,400 | 6,720 | 6,000 | 4,800 | |
Bule | WLL 8T | 8,000 | 6,400 | 16,000 | 11,200 | 8,000 | 5,600 | 4,000 | 11,200 | 8,960 | 8,000 | 6,400 | |
Orange | WLL 10T | 10,000 | 8,000 | 20,000 | 14,000 | 10,000 | 7,000 | 5,000 | 14,000 | 11,200 | 10,000 | 8,000 | |
Orange | WLL 12T | 12,000 | 9,600 | 24,000 | 16,800 | 12,000 | 8,400 | 6,000 | 16,800 | 13,440 | 12,000 | 9,600 | |
Orange | WLL 15T | 15,000 | 12,000 | 30,000 | 21,000 | 15,000 | 10,500 | 7,500 | 21,000 | 16,800 | 15,000 | 12,000 | |
Orange | WLL 20T | 20,000 | 16,000 | 40,000 | 28,000 | 20,000 | 14,000 | 10,000 | 28,000 | 22,400 | 20,000 | 16,000 | |
Orange | WLL 25T | 25,000 | 20,000 | 50,000 | 35,000 | 25,000 | 17,500 | 12,500 | 35,000 | 28,000 | 25,000 | 20,000 | |
Orange | WLL 30T | 30,000 | 24,000 | 60,000 | 42,000 | 30,000 | 21,000 | 15,000 | 42,000 | 33,600 | 30,000 | 24,000 | |
Orange | WLL 50T | 50,000 | 40,000 | 100,000 | 70,000 | 50,000 | 35,000 | 25,500 | 70,000 | 56,000 | 50,000 | 40,000 | |
Orange | WLL 60T | 60,000 | 48,000 | 120,000 | 84,000 | 60,000 | 42,000 | 30,000 | 84,000 | 67,200 | 60,000 | 48,000 | |
Safe usage instructions indicating the correct WLL in a variety of different lifting applications.
We supply a variety of different Webbing Slings to meet customers operational requirements and applications.
