The 2 Tonne Green Polyester Endless Round Sling, also referred to as round textile sling, or Endless Polyester Round Lifting Sling, some customers also called it Green Lifting Sling Round and Round Webbing Sling.
This Polyester Round Sling is constructed from 100% high strength polyester material and features a colour coded system that relates to its load capacity—for instance, green indicates a capacity of 2000kg. Additionally, the sling is protected by a seamless, close-woven, heavy-duty polyester tubular sleeve, ensuring enhanced durability and wear resistance during usage.
This round sling is strong, flexible, and lightweight—lighter than chain, making it less likely to cause damage to loads. It is easy to inspect for damage, boasts high resistance to abrasion, and offers excellent shock-absorbing properties.
Brand | CLGR® |
Standard | EN 1492-2 |
Color | Green |
Material | 100% high tenacity polyester of our sleeve and inner core |
WLL | 2ton / 2000kg Working Load Limit (WLL) |
Safety factor | 5:1, 6:1, 7:1, 8:1 |
Effective working length | 1m to 20m |
Part No. | Colour | Length | W.L.L. | Weight |
m | TON | Kg | ||
CRRS2T01 | Green | 1 | 2 | 0.5 |
CRRS2T02 | 2 | 2 | 0.95 | |
CRRS2T03 | 3 | 2 | 1.45 | |
CRRS2T04 | 4 | 2 | 1.95 |
All slings are color-coded to indicate WLL (Working Load Limit).
Colour | Colour coded according to EN1492-2 | Working load limit with 1 webbing sling | Working load limit with 2 webbing sling | Working load limit with 2 webbing sling - Choked lift up to 45-60° | |||||||||
Straight lift | Choked lift | β | Straight lift up to 45° | Choked lift up to 45° | Straight lift up to 45-60° | ||||||||
0°-7° | 7°-45° | 45°-60° | up to 45° | 45°-60° | |||||||||
|
|
|
|
|
|
|
|
|
| ||||
Violet | WLL 1T | 1,000 | 800 | 2,000 | 1,400 | 1,000 | 700 | 500 | 1,400 | 1,120 | 1,000 | 800 | |
Green | WLL 2T | 2,000 | 1,600 | 4,000 | 2,800 | 2,000 | 1,400 | 1,000 | 2,800 | 2,240 | 2,000 | 1,600 | |
Yellow | WLL 3T | 3,000 | 2,400 | 6,000 | 4,200 | 3,000 | 2,100 | 1,500 | 4,200 | 3,360 | 3,000 | 2,400 | |
Gray | WLL 4T | 4,000 | 3,200 | 8,000 | 5,600 | 4,000 | 2,800 | 2,000 | 5,600 | 4,480 | 4,000 | 3,200 | |
Red | WLL 5T | 5,000 | 4,000 | 10,000 | 7,000 | 5,000 | 3,500 | 2,500 | 7,000 | 5,600 | 5,000 | 4,000 | |
Brown | WLL 6T | 6,000 | 4,800 | 12,000 | 8,400 | 6,000 | 4,200 | 3,000 | 8,400 | 6,720 | 6,000 | 4,800 | |
Bule | WLL 8T | 8,000 | 6,400 | 16,000 | 11,200 | 8,000 | 5,600 | 4,000 | 11,200 | 8,960 | 8,000 | 6,400 | |
Orange | WLL 10T | 10,000 | 8,000 | 20,000 | 14,000 | 10,000 | 7,000 | 5,000 | 14,000 | 11,200 | 10,000 | 8,000 | |
Orange | WLL 12T | 12,000 | 9,600 | 24,000 | 16,800 | 12,000 | 8,400 | 6,000 | 16,800 | 13,440 | 12,000 | 9,600 | |
Orange | WLL 15T | 15,000 | 12,000 | 30,000 | 21,000 | 15,000 | 10,500 | 7,500 | 21,000 | 16,800 | 15,000 | 12,000 | |
Orange | WLL 20T | 20,000 | 16,000 | 40,000 | 28,000 | 20,000 | 14,000 | 10,000 | 28,000 | 22,400 | 20,000 | 16,000 | |
Orange | WLL 25T | 25,000 | 20,000 | 50,000 | 35,000 | 25,000 | 17,500 | 12,500 | 35,000 | 28,000 | 25,000 | 20,000 | |
Orange | WLL 30T | 30,000 | 24,000 | 60,000 | 42,000 | 30,000 | 21,000 | 15,000 | 42,000 | 33,600 | 30,000 | 24,000 | |
Orange | WLL 50T | 50,000 | 40,000 | 100,000 | 70,000 | 50,000 | 35,000 | 25,500 | 70,000 | 56,000 | 50,000 | 40,000 | |
Orange | WLL 60T | 60,000 | 48,000 | 120,000 | 84,000 | 60,000 | 42,000 | 30,000 | 84,000 | 67,200 | 60,000 | 48,000 | |
Safe usage instructions indicating the correct WLL in a variety of different lifting applications.
We supply a variety of different Webbing Slings to meet customers operational requirements and applications.
