CLGR® Eye Type JIS Wooden Pulley Block Double Sheave

Name: CLGR® Eye Type JIS Wooden Pulley Block Double Sheave
Brand: CLGR®

CLGR® Eye Type JIS Wooden Pulley Block Double Sheave, also known as JIS Wooden Pulley Block with Eye Double Sheave.

The Wooden Pulley Block with a wooden shell and hot-dipped galvanized steel components for corrosion protection, is used for re-directing rope, suitable for lifting use.

We offer the great combination of competitive pricing and superior quality—don't hesitate to proceed with your order!

To Get A Quote >

Overview of CLGR® Eye Type JIS Wooden Pulley Block Double Sheave

Brand	China CLGR®
Material	Wooden body and steel wheel
Size	3″, 4″, 5″, 6″, 7″, 8″, 9″, 10″, 11″, 12″
Surface treatment	painted or galvanized

Specifications of CLGR® Eye Type JIS Wooden Pulley Block Double Sheave

Drawing of CLGR® JIS Wooden Pulley Block with Eye Double Sheave

Part No.	Size	SWL/LBS	Diam	∅	L	A	B	Weight(KG)
CRWPDSE-3	3″	800	6mm	45	201	52.5	74.5	0.82
CRWPDSE-4	4″	1400	9mm	57	221	78	86	1.35
CRWPDSE-5	5″	1800	12mm	76	268	98	96	2.3
CRWPDSE-6	6″	2500	14mm	90	322	114	122	3.9
CRWPDSE-7	7″	3000	16mm	121	348	130	130	5.3
CRWPDSE-8	8″	3800	18mm	121	377	145	140	6.8
CRWPDSE-9	9″	4000	20mm	136	418	162	148	9.25
CRWPDSE-10	10″	6000	22mm	158	481	182	166	11
CRWPDSE-11	11″	6000	22mm	178	501	182	166	15
CRWPDSE-12	12″	8000	24mm	196	553	208	184	18
