CLGR® JIS Ship Wooden Block With Shackle Double Sheave

Name: CLGR® JIS Ship Wooden Block With Shackle Double Sheave
Brand: CLGR®

CLGR® JIS Ship Wooden Block With Shackle Double Sheave, also known as JIS Wooden Block With Shackle.

Made of high quality wood and fitted with a hot-dip galvanized steel shackle, this wooden block with shackle minimizes line chafing while providing a smooth 180° rope redirection.

It is designed to work in conjunction with ropes, providing mechanical advantage and changing the direction of force. This allows crew members to handle heavy loads with less effort.

To Get A Quote >

Overview of CLGR® JIS Ship Wooden Block With Shackle Double Sheave

Brand	China CLGR®
Material	Carbon steel/Wood
Craft	Machining/Stamping/Forging/Hot Dipped Galvanized
Size	140inch,180inch, 200inch, 220inch, 240inch
Sheave	Double Sheave

Specification of CLGR® JIS Ship Wooden Block With Shackle Double Sheave

Drawing of CLGR® JIS Ship Wooden Block With Shackle Double Sheave

Part No.	Size	SWL/TON	Diam	∅	L	A	B	Weight(KG)
CRWPSD-1	140mm	0.66	14mm	91	306	112	106	3.69
CRWPSD-2	180mm	1.1	18mm	117	409	144	128	6.3
CRWPSD-3	200mm	1.3	20mm	130	453	160	140	8.96
CRWPSD-4	220mm	1.6	22mm	143	455	176	154	10.55
CRWPSD-5	240mm	1.8	24mm	156	488	192	164	14.18

CLGR® Are Expecting Your Inquiry!
