CLGR® Hay Fork Pulleys With Swivel Eye
This hay fork pulley features a one-piece, all-steel construction that is built to last. The swivel eye allows 360°movement, which reduces rope twist and makes it easier to use. The surface is hot-dip galvanized. This pulley works well with both wire rope and manila rope.
Designed for lifting and rigging tasks, this pulley offers smooth rotation and directional flexibility.
It is ideal for barns, workshops, and general-purpose lifting, providing dependable performance indoors or outdoors.
Brand | CLGR® |
Material | Steel |
Surface Finished | Hot Dipped Galvanized |
Sheave | Single Sheave |
Size | 4″, 6″, 4″, 6″ |
No. | Size | W.L.L | Dia of Rope | Net Weight |
in | ton | in | kg | |
CRSW-4 | 4″ | 1 | 1/2 | 2.36 |
CRSW-6 | 6″ | 2 | 5/8 | 5.95 |
CRSW-8 | 4″ | 1 | 1-1/4 | 2.46 |
CRSW-10 | 6″ | 2 | 1-1/2 | 6.25 |
