CLGR® Steel Rope Pulley Fork Pulley CR03

Name: CLGR® Steel Rope Pulley Fork Pulley CR03
Brand: CLGR®

CLGR® Steel Rope Pulley Fork Pulley is designed for reliable light lifting operations.

Crafted with a steel plate and cast sheave, it's electrically galvanized for enhanced corrosion resistance.

The sturdy steel side plate ensures long-lasting durability, making it ideal for handling steel rope pulleys in various rigging and lifting systems.

Our size is from 4″ to 5″, and WLL from 1T to 2T.

Count on this pulley for smooth, efficient performance in demanding environments.

To Get A Quote >

Overview of CLGR® Steel Rope Pulley Fork Pulley

Material	Super Carbon Steel
Surface Finished	Zinc Plated
Bearing	Smooth Roller Bearing
Color:	Customizable to match specific requirements
Use	Indoor or Outdoor
Size	4″,5″
WLL	1T,2T
Brand	CLGR®
Origin	China

Specification of CLGR® Steel Rope Pulley Fork Pulley

Drawing of CLGR® Steel Rope Pulley Fork Pulley

Part No.	Size	W.L.L	Dia of Rope	Length (L)	Thickness (B)	Width(A)	Net Weight
Part No.	in	ton	mm	mm	mm	mm	kg
CR03B018SP04	4″	1	10	231	51	106	2.2
CR03B018SP05	5″	2	12	297	66	134	3.8
