CLGR® G80 Sling Winch Hook with Half Hammerlock

Name: CLGR® G80 Sling Winch Hook with Half Hammerlock
Brand: CLGR®

CLGR® G80 Sling Winch Hook with Half Hammerlock, also known as G80 Winch Hook Half Link Safety Latch, Grade 80 Safety Hook With Half Link, Grade 80 Sling Hook Hook with Half Coupling Link.

Manufactured from superior forged steel, it delivers outstanding strength and durability, meeting the requirements of high-intensity tasks.

Its G80 grade confirms matching with Grade 80 lifting chains, guaranteeing reliable operation and enhanced safety under the loads.

To Get A Quote >

Overview of G80 Winch Hook Half Link Safety Latch

Brand	CLGR®
Material	Superior Alloy steel
Processing	Drop Forged, Quenched and Tempered
Finish	Powder Coated
Size	7/8mm, 10mm, 13mm, 16mm
Safety Factor	4:1

Specifications of G80 Winch Hook Half Link Safety Latch

Drawing of G80 Sling Winch Hook with Half Hammerlock China Supplier

Part No.	U.W.	W.L.L.	B.L	E±2	B±1	Φ±1.5	K±3	L±3
Part No.	KGS	TONS		MM
8-LG-WH-HL-6	0.35	1.12	4.48	22	15	31	105	132
8-LG-WH-HL-7/8	0.47	2	8	29	18	37	120	149
8-LG-WH-HL-10	1.3	3.15	12.6	35.3	26	47	164	207
8-LG-WH-HL-13	3	5.3	21.2	40	30	60	205	257
8-LG-WH-HL-16	4.4	8	32	44	35	70	224	283.4
8-LG-WH-HL-20	7.3	12.5	50	54.3	41.8	83	264	337.5
8-LG-WH-HL-22	12	15	60	71	57	100	325.6	414.6
