CLGR® Grade 80 Deep Throat Clevis Grab Hook

Name: CLGR® Grade 80 Deep Throat Clevis Grab Hook
Brand: CLGR®

CLGR® Grade 80 Deep Throat Clevis Grab Hook, also known as grade 80 clevis grab hook with saddle, is a type of G80/ Grade 80 chain hoist hook.

Drop forged from alloy steel, quenched and tempered, with a finished surface painted or galvanized, delivers critical load security with a 4:1 safety factor (ultimate load = 4 x WLL), the clevis grab hooks are widely used in connecting chains, master links, or swivels in the lifting & hoisting industry.

Avaliable size in 6mm, 7/8mm, 10mm, 13mm, these eye grab hooks passed the fatigue test and break load test.

To Get A Quote >

CLGR® Grade 80 Deep Throat Eye Grab Hook

CLGR® Grade 80 Deep Throat Eye Grab Hook China Factory

CLGR® Grade 80 Deep Throat Eye Grab Hook China Supplier

CLGR® Grade 80 Deep Throat Eye Grab Hook China

CLGR® Grade 80 Deep Throat Eye Grab Hook China Manufacturer

 

Overview of CLGR® Grade 80 Deep Throat Clevis Grab Hook

Brand	CLGR®
Standard	EN1677
Material	Super Alloy Steel
Safety Factor	4: 1
Processing	Drop Forged / Quenched and Tempered
Finish	Powder Coated
Size	6mm, 7/8mm, 10mm, 13mm
Tips	Color Code Can be customized according to customers' requirements
Note	Never exceed working load limit

Specifications of CLGR® Grade 80 Deep Throat Clevis Grab Hook

drawing-clgr-of-clgr-grade-80-deep-throat-clevis-grab-hook-china-supplier

Part No.	WEIGHT (KG)	WLL (T)	B.L (T)	A±2 (mm)	B±2 (mm)	E±2 (mm)	M±3 (mm)	L±3 (mm)
8CRCGHDT06	0.2	1.12	4.48	7.5	31.5	8	45	85
8CRCGHDT7/8	0.5	2	8	9	37.5	10.5	57	106
8CRCGHDT10	0.75	3.15	12.6	12.5	47.5	13	74	127
8CRCGHDT13	1.63	5.3	21.2	15	58.5	15.5	89	165.5

*Ultimate load is 4 times the Working Load Limit.
