CLGR® Grade 70 Transport Chain Binder Chain US Fed. Spec.

Name: CLGR® Grade 70 Transport Chain Binder Chain US Fed. Spec.
Brand: CLGR®

CLGR® Grade 70 Transport Chain Binder Chain US Fed. Spec., also known as Grade 70 Chain and Binder Kit, G70 Chain & Binder Kit, binder chain.

The Grade 70 Transport Chain Binder provides a strong, reliable hold for securing heavy loads on trucks or flatbed trailers.

Manufactured from heat-treated Grade 70 carbon steel and finished with corrosion-resistant yellow passivated (zinc-chromate), it is ideal for demanding industrial, agricultural, logging, and towing applications.

Available in a range of chain sizes ( 1/4″, 5/16″, 3/8″, 7/16″, 1/2″, 5/8″, 3/4″ ) and backed by a limited lifetime warranty, this ratchet binder kit is built for performance and durability.

To Get A Quote >

Grade 70 Transport Binder Chain China Manufacturer

Grade 70 Transport Binder Chain China Factory

Grade 70 Transport Binder Chain China Supplier

 

Overview of CLGR® Grade 70 Transport Chain Binder Chain US Fed. Spec.

Brand	CLGR®
Technical Notes	G70 transport chain Conform to NACM96
Material	High-strength, Alloy steel
Processing	Welded
Finish	Yellow Passivated
Size	1/4″, 5/16″, 3/8″, 7/16″, 1/2″, 5/8″, 3/4″
Safety Factor	4:1

Specifications of CLGR® Grade 70 Transport Chain Binder Chain US Fed. Spec.

Part No.	Nominal Chain Size		Material Diameter		Working Load Limit (MAX.)		Proof Test (Min.)		Breaking Force (Min.)		Inside Length (Max.)		Inside Width (Max.)		Weight Kgs/100FT
Part No.	INCH	MM	INCH	MM	LBS	KG	LBS	KN	LBS	KN	INCH	MM	INCH	MM	Weight Kgs/100FT
CRWC2001	1/4”	7	0.281	7	3150	1430	6300	28	12600	56	1.24	31.5	0.38	9.8	28.12
CRWC2002	5/16”	8.7	0.343	8.7	4700	2130	9400	41.8	18800	83.6	1.29	32.8	0.44	11.2	45.84
CRWC2003	3/8”	10	0.406	10.3	6600	2990	13200	58.7	26400	117.4	1.38	35	0.55	14	67.41
CRWC2004	7/16”	11.9	0.468	11.9	8750	3970	17500	77.8	35000	155.4	1.64	41.6	0.65	16.6	89.26
CRWC2005	1/2”	13	0.531	13.5	11300	5130	22600	100.4	45200	200.8	1.79	45.5	0.72	18.2	116.06
CRWC2006	5/8”	16	0.63	16	15800	7170	31600	140.4	63200	280.8	2.2	56	0.79	20	159.01
CRWC2007	3/4”	20	0.787	20	24700	11200	49400	219.6	98800	439.2	2.76	70	0.98	25	248.46
