CLGR® Stud Link Anchor Chain - The China Manufacturer Supplier, Factory

Name: CLGR® Stud Link Anchor Chain - The China Manufacturer Supplier, Factory
Brand: CLGR®

CLGR® Stud Link Anchor Chain, also known as Stud Offshore Mooring Chain, Stud-Link Anchor Chain and Anchor link adaptor common link.

The Studlink chains are used for anchor and mooring chains, stud link chains have a central stud for extra strength. The Studlink anchor chain for sale is available in black (tarred) and galvanised.

The CLGR® Stud link chains feature a crossbar (stud) in each link, which strengthens the structure to resist bending under heavy loads. This design also reduces wear from friction between links, while the added rigidity simplifies maintenance. Additionally, the stud prevents tangling, ensuring smoother operation with winches and windlasses. Ideal for large vessels such as tankers and commercial ships, the Studlink anchor chain for sale excels in high-stress applications that require a robust strength-to-weight ratio.

As one of the professional lifting chain manufacturers, CLGR® invites you to browse our comprehensive range of anchor chain for sale to meet your most demanding maritime requirements.

To Get A Quote >

Overview of CLGR® Stud Link Anchor Chain

Brand	CLGR®
Size	12.5mm, 14mm, 16mm, 17.5mm, 19mm, 20.5mm, 22mm,24mm, 26mm, 28mm, 30mm, 32mm, 34mm, 36mm, 38mm, 40mm,42mm, 44mm, 46mm, 48mm, 50mm,52mm, 54mm, 56mm,58mm, 60mm, 62mm, 64mm, 66mm, 68mm,70mm, 73mm, 76mm, 78mm, 81mm,84mm, 87mm, 90mm,92mm, 95mm, 97mm, 100mm, 102mm, 105mm, 107mm, 111mm, 114mm, 117mm, 120mm,122mm, 124mm, 127mm,130mm
Material	Superior Alloy Steel
Processing	Welded, Heat Treated
Surface Finish	Hot Dipped Galvanized
Note	NOT FOR OVERLOAD LIFTING

Specification of CLGR® Stud Link Anchor Chain

drawing-of-clgr®-stud-link-anchor-chain-china-supplier

Specification 1

Part No.	d(φ)		AM1		AM2		AM3		APPROX.
			U1 Stud Link Chain		U2 Stud Link Chain		U3 Stud Link Chain		Weight
			U1 Stud Link Chain		U2 Stud Link Chain		U3 Stud Link Chain		PER
	Diameter		Proof Load (kn.)	Breaking Load (kn.)	Proof Load (kn.)	Breaking Load (kn.)	Proof Load (kn.)	Breaking Load (kn.)	27.5m
	(in.)	(mm.)	Proof Load (kn.)	Breaking Load (kn.)	Proof Load (kn.)	Breaking Load (kn.)	Proof Load (kn.)	Breaking Load (kn.)	kg
CR-SL-C-12.5	1/2	12.5	46	66	66	92	92	132	98
CR-SL-C-14	9/16	14	58	82	82	116	116	165	119
CR-SL-C-16	5/8	16	76	107	107	150	150	216	156
CR-SL-C-17.5	11/16	17.5	89	127	127	179	179	256	186
CR-SL-C-19	3/4	19	105	150	150	211	211	301	230
CR-SL-C-20.5	13/16	20.5	123	175	175	244	244	349	260
CR-SL-C-22	7/8	22	140	200	200	280	280	401	300
CR-SL-C-24	15/16	24	167	237	237	332	332	476	370
CR-SL-C-26	1-1/16	26	194	278	278	389	389	556	431
CR-SL-C-28	1-1/8	28	225	321	321	449	449	642	496
CR-SL-C-30	1-3/16	30	257	368	368	514	514	735	564
CR-SL-C-32	1-1/4	32	291	417	417	583	583	833	635
CR-SL-C-34	1-5/16	34	328	468	468	655	655	937	712
CR-SL-C-36	1-7/16	36	366	523	523	732	732	1050	800
CR-SL-C-38	1-1/2	38	406	581	581	812	812	1160	887
CR-SL-C-40	1-9/16	40	448	640	640	896	896	1280	1032

Specification 2

Part No.	d(φ)		BM1		BM2		BM3		Approx.
	d(φ)		U1 Open Link Chain		U2 Open Link Chain		U3 Open Link Chain		Weight
	Diameter		Proof Load (kn.)	Breaking Load (kn.)	Proof Load (kn.)	Breaking Load (kn.)	Proof Load (kn.)	Breaking Load (kn.)	Per
	(in.)	(mm.)	Proof Load (kn.)	Breaking Load (kn.)	Proof Load (kn.)	Breaking Load (kn.)	Proof Load (kn.)	Breaking Load (kn.)	27.5M Kg.
CR-SL-C-42	1-5/8	42	492	703	703	981	981	1400	1084
CR-SL-C-44	1-3/4	44	538	769	769	1080	1080	1540	1197
CR-SL-C-46	1-13/16	46	585	837	837	1170	1170	1680	1310
CR-SL-C-48	1-7/8	48	635	908	908	1270	1270	1810	1438
CR-SL-C-50	2	50	686	981	981	1370	1370	1960	1546
CR-SL-C-52	2-1/16	52	739	1060	1060	1480	1480	2110	1661
CR-SL-C-54	2-1/8	54	794	1140	1140	1590	1590	2270	1791
CR-SL-C-56	2-3/16	56	851	1220	1220	1710	1710	2430	1926
CR-SL-C-58	2-5/16	58	909	1290	1290	1810	1810	2600	2086
CR-SL-C-60	2-3/8	60	969	1380	1380	1940	1940	2770	2249
CR-SL-C-62	2-7/16	62	1030	1470	1470	2060	2060	2940	2361
CR-SL-C-64	2-1/2	64	1100	1560	1560	2190	2190	3130	2516
CR-SL-C-66	2-9/16	66	1160	1660	1660	2310	2310	3300	2676
CR-SL-C-68	2-11/16	68	1230	1750	1750	2450	2450	3500	2885
CR-SL-C-70	2-3/4	70	1290	1840	1840	2580	2580	3690	3010

Specification 3

Part No.	d(φ)	AM2		AM3		Approx.
		U2 Stud Link Chain		U3 Stud Link Chain		Weight
	Diameter					Per
						27.5M
	(mm.)	Proof Load (kn.)	Breaking Load (kn.)	Proof Load (kn.)	Breaking Load (kn.)	Kg.


CR-SL-C-73	73	1990	2790	2790	3990	3274
CR-SL-C-76	76	2150	3010	3010	4300	3548
CR-SL-C-78	78	2260	3160	3160	4500	3737
CR-SL-C-81	81	2410	3380	3380	4820	4030
CR-SL-C-84	84	2580	3610	3610	5160	4334
CR-SL-C-87	87	2750	3850	3850	5500	4650
CR-SL-C-90	90	2920	4090	4090	5840	4976
CR-SL-C-92	92	3040	4260	4260	6080	5119
CR-SL-C-95	95	3230	4510	4510	6440	5544
CR-SL-C-97	97	3340	4680	4680	6690	5780
CR-SL-C-100	100	3530	4940	4940	7060	6143
CR-SL-C-102	102	3660	5120	5120	7320	6398
CR-SL-C-105	105	3850	5390	5390	7700	6773
CR-SL-C-107	107	3980	5570	5570	7960	7033
CR-SL-C-111	111	4250	5940	5940	8480	7569
CR-SL-C-114	114	4440	6230	6230	8890	7983
CR-SL-C-117	117	4650	6510	6510	9300	8409
CR-SL-C-120	120	4850	6810	6810	9720	8863
CR-SL-C-122	122	5000	7000	7000	9990	9143
CR-SL-C-124	124	5140	7200	7200	10280	9598
CR-SL-C-127	127	5350	7490	7490	10710	9908
CR-SL-C-130	130	5570	7800	7800	11140	10382
