CLGR® Nylon Rope Wooden Block Single Wheel

CLGR® Nylon Rope Wooden Block Single Wheel, also known as Nylon Rope Wooden Pulley, External Bound Wooden Block.


Nylon Rope Wooden Block, available with single or double sheave, is fitted with a thimble and shackle. The thimble prevents rope chafing while the shackle provides secure rigging attachment. Ideal for sail handling, mast rigging, and cargo lifting on ships.


Available in a range of sizes: 100in, 120in, 140in, 180in to suit various rigging configurations.

To Get A Quote >
CLGR® Nylon Rope Wooden Block Single Wheel
CLGR® Nylon Rope Wooden Block Single Wheel

Overview of CLGR® Nylon Rope Wooden Block Single Wheel

Brand

China CLGR®

Materials

Wood and Super Carbon Steel

Craft

Machining/Stamping/Forging/Hot Dipped Galvanized

Size

100inch, 120inch, 140inch, 180inch


Specification of CLGR® Nylon Rope Wooden Block Single Wheel

Drawing of CLGR® Nylon Rope Wooden Block Single Wheel

Part No.

Size

SWL/TON

Diam

L

A

B

Weight(KG)

CRNWPS

100mm

0.4

10mm

65

285

80

77

0.62

CRNWPS

120mm

0.52

12mm

80

345

90

92

1.1

CRNWPS

140mm

0.72

14mm

90

415

105

105

2.74

CRNWPS

180mm

1.16

18mm

120

520

128

124

3.9
