CLGR® Closed Type Pulley Block with Eye Single Sheave 7411

Name: CLGR® Closed Type Pulley Block with Eye Single Sheave 7411
Brand: CLGR®

CLGR® Closed Type Pulley Block with Eye Single Sheave 7411, also known as Close Type Single Sheave Pulley, Single Sheave Pulley Close Type Eye Hook.

Finish options include painted or hot dip galvanized for corrosion protection.

The enclosed design keeps the rope securely in the sheave groove during operation. Eye attachment provides a reliable and flexible mounting point.

Available in various sizes: 2'', 3'', 4'', 5'', 6'', 7'', 8'', 10'', 12''.

Working load limits: 0.25t, 0.5t, 1t, 1.5t, 2t, 3t, 4t, 5t, 6t.

To Get A Quote >

CLGR® Closed Type Pulley Block with Eye Single Sheave 7411 China Manufacturer

CLGR® Closed Type Pulley Block with Eye Single Sheave 7411 China Supplier

CLGR® Closed Type Pulley Block with Eye Single Sheave 7411

Overview of CLGR® Closed Type Pulley Block with Eye Single Sheave 7411

Brand	China CLGR®
Type	Single Sheave Block 7312
Material	Steel
Surface	Color Painted or Galvanized
Size	2″, 3″, 4″, 5″, 6″, 7″, 8″, 10″, 12″
Application	Lifting Equipment

Specifications of CLGR® Closed Type Pulley Block with Eye Single Sheave 7411

drawing-of-clgr®-closed-type-pulley-block-with-eye-single-sheave-7411-china-manufacturer

Part No.	Size	SWL/Ton	Dia.	∅	L	A	B	C	Weight(KG)
CR7411E-2	2″	0.25	6mm	50	186	58	42	11	0.65
CR7411E-3	3″	0.5	8mm	71	287.5	88	57	10	1.4
CR7411E-4	4″	1	10mm	96	327.5	112	63	15	2.65
CR7411E-5	5″	1.5	13mm	121	381	140	68	17	4.2
CR7411E-6	6″	2	16mm	148	445	164	76	20	6.2
CR7411E-7	7″	3	19mm	173	511	196	84	22	8.5
CR7411E-8	8″	4	22mm	200	553	220	89	26	11.5
CR7411E-10	10″	5	25mm	250	632.5	272	89	28	16.5
CR7411E-12	12″	6	28mm	300	705	320	95	28	23
