CLGR® Galvanized Snatch Block with Eye for Manila Rope is designed for general lifting purposes and onboard ship applications, offering reliable performance in diverse operational environments.
A standout feature is its swivelling oval eye, which is both swivelling and jointedly attached to the cross head, enabling flexible adjustment to adapt to different lifting angles and force directions.
Crafted from high-quality materials, the block features structural steel for the main frame, with forged steel oval eyes and cross head for superior strength.
The sheave bushings are made from red metal, further optimizing durability and operational efficiency in demanding lifting scenarios. The block is equipped with covering side plates reinforced by separate steel supports, ensuring structural stability during heavy-duty use.
It incorporates key hole type locking for secure operation, preventing accidental disengagement during lifting.
Brand | CLGR® |
Material | Structural steel, forged oval eyes and cross head of steel, sheave bushing of red metal. |
Size | 4″, 6″, 8″, 10″, 12″ |
WLL | From 1200 LBS to 9600 LBS |
Warning | Do not exceed working load limit (WLL). |
Size | W.L.L | Dia of Rope | Net Weight | |
in | lbs | in | kg | |
CRWHS204 | 4″ | 1200 | 3/4 | 1.5 |
CRWHS206 | 6″ | 2400 | 7/8 | 3.75 |
CRWHS208 | 8″ | 4800 | 1-1/8 | 5.6 |
CRWHS210 | 10″ | 6600 | 1-1/4 | 10 |
CRWHS212 | 12″ | 9600 | 1-1/2 | 17.5 |
