CLGR® 8 Tonne/8000KG Lifting Sling Blue Polyester Endless Round Sling, also referred to as round textile sling, or Endless Polyester Round Lifting Sling, some customers also called it Blue Lifting Sling Round and Round Webbing Sling.
Manufactured from 100% high strength polyester and conformed to the European Standard EN1492, the round slings are classed as the all purpose lifting aid capable of high endurance lifting tasks, great for sliding under low height objects to create a flexible and lightweight lifting sling.
This 8000kg round sling is strong, flexible, and lightweight—lighter than chain, making it less likely to cause damage to loads. It is easy to inspect for damage, boasts high resistance to abrasion, and offers excellent shock-absorbing properties.
| Brand | CLGR® |
| Standard | EN 1492 |
| Color | Blue |
| Material | 100% high tenacity polyester of our sleeve and inner core |
| WLL | 8ton / 8000kg Working Load Limit (WLL) |
| Safety factor | 5:1, 6:1, 7:1, 8:1 |
| Effective working length | 1m to 20m |
Part No. | Color | Length | W.L.L. | Weight |
m | TON | kg | ||
CRRS8T02D | Blue | 2 | 8 | 3.4 |
CRRS8T03D | Blue | 3 | 8 | 5.1 |
CRRS8T04D | Blue | 4 | 8 | 6.8 |
CRRS8T05D | Blue | 5 | 8 | 8.35 |
CRRS8T06D | Blue | 6 | 8 | 10 |
CRRS8T08D | Blue | 8 | 8 | 13.25 |
CRRS8T010D | Blue | 10 | 8 | 16.6 |
All slings are color-coded to indicate WLL (Working Load Limit).
Colour | Colour coded according to EN1492-2 | Working load limit with 1 webbing sling | Working load limit with 2 webbing sling | ||||||||||
Straight lift | Choked lift | β | Straight lift up to | Choked lift up to | Straight lift up to | Choked lift up to | |||||||
0°-7° | 7°-45° | 45°-60° | up to 45° | 45°-60° | 45° | 45° | 45-60° | 45-60° | |||||
 |
|
|
|
|
|
|
|
|
|  | |||
Violet | WLL 1T | 1,000 | 800 | 2,000 | 1,400 | 1,000 | 700 | 500 | 1,400 | 1,120 | 1,000 | 800 | |
Green | WLL 2T | 2,000 | 1,600 | 4,000 | 2,800 | 2,000 | 1,400 | 1,000 | 2,800 | 2,240 | 2,000 | 1,600 | |
Yellow | WLL 3T | 3,000 | 2,400 | 6,000 | 4,200 | 3,000 | 2,100 | 1,500 | 4,200 | 3,360 | 3,000 | 2,400 | |
Gray | WLL 4T | 4,000 | 3,200 | 8,000 | 5,600 | 4,000 | 2,800 | 2,000 | 5,600 | 4,480 | 4,000 | 3,200 | |
Red | WLL 5T | 5,000 | 4,000 | 10,000 | 7,000 | 5,000 | 3,500 | 2,500 | 7,000 | 5,600 | 5,000 | 4,000 | |
Brown | WLL 6T | 6,000 | 4,800 | 12,000 | 8,400 | 6,000 | 4,200 | 3,000 | 8,400 | 6,720 | 6,000 | 4,800 | |
Bule | WLL 8T | 8,000 | 6,400 | 16,000 | 11,200 | 8,000 | 5,600 | 4,000 | 11,200 | 8,960 | 8,000 | 6,400 | |
Orange | WLL 10T | 10,000 | 8,000 | 20,000 | 14,000 | 10,000 | 7,000 | 5,000 | 14,000 | 11,200 | 10,000 | 8,000 | |
Orange | WLL 12T | 12,000 | 9,600 | 24,000 | 16,800 | 12,000 | 8,400 | 6,000 | 16,800 | 13,440 | 12,000 | 9,600 | |
Orange | WLL 15T | 15,000 | 12,000 | 30,000 | 21,000 | 15,000 | 10,500 | 7,500 | 21,000 | 16,800 | 15,000 | 12,000 | |
Orange | WLL 20T | 20,000 | 16,000 | 40,000 | 28,000 | 20,000 | 14,000 | 10,000 | 28,000 | 22,400 | 20,000 | 16,000 | |
Orange | WLL 25T | 25,000 | 20,000 | 50,000 | 35,000 | 25,000 | 17,500 | 12,500 | 35,000 | 28,000 | 25,000 | 20,000 | |
Orange | WLL 30T | 30,000 | 24,000 | 60,000 | 42,000 | 30,000 | 21,000 | 15,000 | 42,000 | 33,600 | 30,000 | 24,000 | |
Orange | WLL 50T | 50,000 | 40,000 | 100,000 | 70,000 | 50,000 | 35,000 | 25,500 | 70,000 | 56,000 | 50,000 | 40,000 | |
Orange | WLL 60T | 60,000 | 48,000 | 120,000 | 84,000 | 60,000 | 42,000 | 30,000 | 84,000 | 67,200 | 60,000 | 48,000 | |
Safe usage instructions indicating the correct WLL in a variety of different lifting applications.
We supply a variety of different Webbing Slings to meet customers operational requirements and applications.
