CLGR® Malleable Iron Shell Block Double Sheave With Swivel Hook

Name: CLGR® Malleable Iron Shell Block Double Sheave With Swivel Hook
Brand: CLGR®

CLGR® Malleable Iron Shell Block Single Sheave With Swivel Hook, also known as swivel hook malleable pulley.

Constructed with a robust steel shell, this block is designed for demanding applications and features bronze self-lubricating bushings as standard.

Used for manila rope, bronze pressure-lubricated bushings are available upon request.

Rated for WLL: 1,600, 3,300, 5,100, 8,800, and 11,000 lbs., each unit is permanently marked with size and WLL, and test certifications are supplied upon request.

To Get A Quote >

CLGR® Malleable Iron Shell Block Double Sheave With Swivel Hook

CLGR® Malleable Iron Shell Block Double Sheave With Swivel Hook China Supplier

Overview of Malleable Iron Shell Block Double Sheave With Swivel Hook

Brand	CLGR®
Type	Double Sheave With Swivel Hook
Material	Malleable Iron
Surface Finished	Hot Dipped Galvanized
Size	4″, 6″, 8″, 10″, 12″

Specifications of Malleable Iron Shell Block Double Sheave With Swivel Hook

Drawing of Malleable Iron Shell Block Triple Sheave With Swivel Hook

No.	Size	W.L.L	Dia of Rope	L	B	A	Net Weight
No.	in	lbs	in	mm	mm	mm	kg
CRMBDSSH-4	4″	1600	1/2″	286	85	74	1.9
CRMBDSSH-6	6″	3300	3/4″	395	100	109	5.5
CRMBDSSH-8	8″	5100	1″	517	122	145	11
CRMBDSSH-10	10″	8800	1-1/4″	595	157	182	16.5
CRMBDSSH-12	12″	11000	1-1/4″	732	157	236	28

CLGR® Are Expecting Your Inquiry!

We design, manufacture and distribute products and provide services for lifting and material handling applications, the construction metal industry, the trawl industry and the yacht accessories industry.
