CLGR® Malleable Iron Shell Block Double Sheave with Hook

Name: CLGR® Malleable Iron Shell Block Double Sheave with Hook
Brand: CLGR®

CLGR® Malleable Iron Shell Block Double Sheave with Hook, also known as Malleable Double Sheave Pulley, Steel Shell Blocks For Fiber Rope.

Made for manila rope, malleable iron shell block double sheave comes with a hook and a galvanized body.

Available in sizes 4", 6", 8", 10", 12" with corresponding WLL of 1,600, 3,300, 5,100, 8,800, and 11,000 lbs. Each unit is marked with size and WLL. Certification available upon request.

To Get A Quote >

CLGR® Malleable Iron Shell Block Double Sheave with Hook

CLGR® Malleable Iron Shell Block Double Sheave with Hook China Manufacturer

CLGR® Malleable Iron Shell Block Double Sheave with Hook China Supplier

Overview of Malleable Iron Shell Block Double Sheave with Hook

Brand	CLGR®
Type	Malleable Iron Shell Block Double Sheave with Hook
Material	Malleable Iron
Surface Finished	Hot Dipped Galvanized
Size	4″, 6″, 8″, 10″, 12″
Origin	China

Specifications of Malleable Iron Shell Block Double Sheave with Hook

drawing-of-malleable-iron-shell-block-double-sheave-with-hook-china-supplier

No.	Size	W.L.L	Dia of Rope	L	B	A	Net Weight
No.	in	lbs	in	mm	mm	mm	kg
CRMBDSH-4	4″	1600	1/2	287	85	74	2.0
CRMBDSH-6	6″	3300	3/4	400	100	109	5.15
CRMBDSH-8	8″	5100	1	532	122	145	10.5
CRMBDSH-10	10″	8800	1-1/4	638	157	182	16
CRMBDSH-12	12″	11000	1-1/4	712	157	236	–
