CLGR® JIS Wood Pulley Double Sheave With Hook

Name: CLGR® JIS Wood Pulley Double Sheave With Hook
Brand: CLGR®

CLGR® JIS Wood Pulley Double Sheave With Hook, also known as JIS Wooden Pulley Block with Hook.

This JIS Wood Pulley has wood shells with a hook fitting design. The fittings are forged for extra strength. Bronze self-lubricating bushings ensure smooth operation, and galvanized metal parts provide reliable corrosion resistance.

To Get A Quote >

Overview of CLGR® JIS Wood Pulley Double Sheave With Hook

Brand	China CLGR®
Material	Wooden body and steel wheel
Size	3″, 4″, 5″, 6″, 7″, 8″, 9″, 10″, 11″, 12″
Surface treatment	Painted or Galvanized

Specification of CLGR® JIS Wood Pulley Double Sheave With Hook

Drawing of CLGR® JIS Wood Pulley Double Sheave With Hook

Part No.	Size	SWL/LBS	Diam	∅	L	A	B	Weight(KG)
CRWPDSH-3	3″	800	6mm	45	235	52.5	74.5	0.82
CRWPDSH-4	4″	1400	9mm	57	255	78	86	1.56
CRWPDSH-5	5″	1800	12mm	76	302	98	96	2.3
CRWPDSH-6	6″	2500	14mm	90	352	114	122	3.9
CRWPDSH-7	7″	3000	16mm	121	378	130	130	5.3
CRWPDSH-8	8″	3800	18mm	121	407	140	140	7.5
CRWPDSH-9	9″	4000	20mm	136	461	148	148	9.25
CRWPDSH-10	10″	6000	22mm	158	504	166	166	11
CRWPDSH-11	11″	6000	22mm	178	524	166	166	15
CRWPDSH-12	12″	8000	24mm	196	701	184	184	18
