CLGR® JIS Ship Wooden Block With Link Single Sheave

Name: CLGR® JIS Ship Wooden Block With Link Single Sheave
Brand: CLGR®

CLGR® JIS Ship Wooden Block With Link Single Sheave, also known as JIS Wood Pulley With Link.

This JIS Wood Pulley With Link is a critical component for traditional and modern sailing vessels, engineered specifically for lifting sails, adjusting rigging, and mast control.

Crafted from high quality wood and fitted with a hot-dip galvanized steel link, this wooden block minimizes line chafing while providing a smooth 180° rope redirection.

It is designed to work in conjunction with ropes, providing mechanical advantage and changing the direction of force. This allows crew members to handle heavy loads with less effort.

Surface treated with galvanization for marine environments. Available in sizes from 180inch to 240inch to suit various rope diameters.

To Get A Quote >

Overview of CLGR® JIS Ship Wooden Block With Link Single Sheave

Brand	China CLGR®
Material	Carbon steel/Wood
Craft	Machining/Stamping/Forging/Hot Dipped Galvanized
Size	180inch, 200inch, 220inch, 240inch
Sheave	Single Sheave

Specification of CLGR® JIS Ship Wooden Block With Link Single Sheave

Drawing of CLGR® JIS Ship Wooden Block With Link Single Sheave

Part No.	Size/in	SWL/Ton	Diam	∅	L	A	B	Weight(KG)
CRJWBL01	180	0.29	18mm	117	332	144	82	3.62
CRJWBL02	200	0.35	20mm	130	366	160	89	4.73
CRJWBL03	220	0.42	22mm	143	399	176	97	6.48
CRJWBL04	240	0.5	24mm	156	422	192	103	8.44

CLGR® Are Expecting Your Inquiry!

We design, manufacture and distribute products and provide services for lifting and material handling applications, the construction metal industry, the trawl industry and the yacht accessories industry.
