CLGR® Grade 80 Alloy Pear Links

Name: CLGR® Grade 80 Alloy Pear Links
Brand: CLGR®

CLGR® Grade 80 Alloy Pear Links, also known as Pear Link, Pear Shape Master Links.

Unlike oblong master links suited for larger assemblies, pear-shaped links are designed for compact rigging.

The Pear Link accommodates up to two-leg chain slings, wire rope bridles, and similar connections while excelling in narrow-hook applications.

The pear shape links often provide a snugger fit than oblong links, minimizing side-to-side load movement on the hook surface for enhanced stability.

To Get A Quote >

CLGR® Grade 80 Alloy Pear Links China Supplier

Overview of CLGR® Grade 80 Alloy Pear Links

Brand	CLGR®
Standard	US Federal Specification
Material	Super Alloy steel
Processing	Drop Forged
Finish	Powder Coated
Size	3/8", 1/2", 5/8", 3/4", 7/8", 1", 1-1/4", 1-3/8", 1-1/2", 1-3/4", 2"
Safety Factor	5:1
Tips	G80 components. Suitable for use with G80 chain.

Specifications of CLGR® Grade 80 Alloy Pear Links

Drawing of CLGR® Grade 80 Alloy Pear Links China Supplier

Part No.	Diameter	Inside Length	Inside Width		Each Weight	W.L.L (Single Pull)
Part No.	Diameter	Inside Length	Small end	Large end	Each Weight	Alloy
Alloy	inch	inch	inch	inch	lbs	lbs
8CRPL3/8	3/8”	2.25	0.75	1.5	0.23	*
8CRPL1/2	1/2”	3	1	2	0.55	7000
8CRPL5/8	5/8”	3.75	1.25	2.5	1.1	9000
8CRPL3/4	3/4”	4.5	1.5	3	1.95	12300
8CRPL7/8	7/8”	5.25	1.75	3.5	2.78	14000
8CRPL1	1”	6	2	4	4.3	24360
8CRPL1-1/4	1-1/4”	7.75	2.5	5	8.5	36000
8CRPL1-3/8	1-3/8”	8.25	2.75	5.5	11.5	43000
8CRPL1-1/2	1-1/2”	9	3	6	15.25	54300
8CRPL1-3/4	1-3/4”	10.5	3.5	7	22.5	84900
8CRPL2	2”	12	4	8	34	102600

CLGR® Are Expecting Your Inquiry!

We design, manufacture and distribute products and provide services for lifting and material handling applications, the construction metal industry, the trawl industry and the yacht accessories industry.
