CLGR® Stainless Steel Swage Eye Terminals

Name: CLGR® Stainless Steel Swage Eye Terminals
Brand: CLGR®

CLGR® Stainless Steel Swage Eye Terminal, also known as Stainless Swage Eye and Wire Rope Swage Eye Terminal.

Constructed of 316 stainless steel, these swage marine eyes offer an excellent blend of strength and superior corrosion resistance. Each eye, sized for a specific wire diameter, is designed to be machine swaged. For the same wire diameter, multiple pin diameters may be available to match existing rigging configurations.

Note: Always match terminal size to anchor points and use appropriate hydraulic tools for swaging. It will not work with a Crenshaw hand swager.

To Get A Quote >

CLGR® Stainless Steel Swage Eye Terminals

 

Overview of CLGR® Stainless Steel Swage Eye Terminals

Brand	CLGR®
Material	Stainless Steel
Size	2mm, 2.5mm, 3mm, 4mm, 5mm, 6mm, 7mm, 8mm 10mm, 12mm, 14mm, 16mm, 19mm, 22mm, 26mm
Processing	Stamping / Machining
Finish	Highly Polishing
Warning	Not rated for lifting

Specifications of CLGR® Stainless Steel Swage Eye Terminals

Part No.	Wire (mm)	A (mm)	B (mm)	D (mm)	D1 (mm)	D2 (mm)	L1 (mm)	L (mm)	KG/100	B.L. (KG)
CRSSSTERE02	2	3	13	5.4	2.2	5.5	30	48.5	0.9	800
CRSSSTERE25	2.5	3	13	5.4	2.7	5.5	30	48.5	0.9	800
CRSSSTERE03	3	4	14	6.5	3.3	6.35	36	55	1.5	1300
CRSSSTERE04	4	6	18	8.5	4.3	7.5	39	65	2.5	2350
CRSSSTERE05	5	7	22	10	5.3	9	50	80	4.5	3500
CRSSSTERE06	6	8	28	12.5	6.4	12.6	62	94	9.5	5600
CRSSSTERE07	7	9	28	12.5	7.4	14.2	68	105	12.5	6200
CRSSSTERE08	8	10	32	14.5	8.4	16	85	124	18.2	7600
CRSSSTERE10	10	12	36	16.4	10.5	18	90	142	25.2	9800
CRSSSTERE12	12	16	40	19.3	12.6	20	105	160	42.5	13000
CRSSSTERE14	14	18	47	23	14.7	25	140	206	75.5	17000
CRSSSTERE16	16	20	53	26	16.9	28	160	232	102	24000
CRSSSTERE19	19	25	65	28.5	20	34.5	200	302	209	27000
CRSSSTERE22	22	30	70	33	23.2	40.5	230	348	314	31000
CRSSSTERE26	26	30	77	36	27.5	46	280	400	425	43000
