CLGR® Grade 80 Viking Master Link, also known as Recessed Link EVM, Viking Recessed Master Link, Master Links EVM.
Made of superior alloy steel, designing for overhead lifting, picking, placing, and towing applications.
The recessed design of the Viking Master Link enables quick connection with G-hooks, effectively improving work efficiency.
We offer alloy forged recessed links in standard sizes, with the option for custom sizing to suit your requirements.
Brand | CLGR® |
WLL | 1T, 1.5T, 3T, 3.2T, 4.4T, 5.6T, 10T, 12T, 15T, 20T |
| Material | Superior Alloy Steel |
Safety Factor | 5: 1 |
Processing | Drop Forged / Heat Treatment |
Surface Finish | Powder Coating |
Important Note | Never exceed Working Load Limit |
Part No. | WLL | B /mm | A /mm | C /mm | D /mm | E /mm | d /mm | R /mm | F /mm | L /mm | W.T/KG |
8CR-EVM-VML20T | 20T | 76.5 | 42.5 | 100 | 25 | 36 | 34 | 3 | 85 | 185 | 4.2 |
8CR-EVM-VML15T | 15T | 67.5 | 37.5 | 95 | 17 | 32 | 30 | 2.5 | 75 | 170 | 2.8 |
8CR-EVM-VML12T | 12T | 49 | 24 | 74 | 16 | 28 | 25 | 2 | 48 | 122 | 1.7 |
8CR-EVM-VML10T | 10T | 40.25 | 18.75 | 63.5 | 14 | 22.6 | 21 | 1.5 | 37.5 | 101 | 0.82 |
8CR-EVM-VML5.6T | 5.6T | 58 | 30 | 90 | 21 | 32 | 28 | 1.5 | 60 | 150 | 2.1 |
8CR-EVM-VML4.4T | 4.4T | 50 | 25 | 80 | 18 | 30 | 25 | 1.5 | 50 | 130 | 1.5 |
8CR-EVM-VML3.2T | 3.2T | 42.5 | 22.5 | 65 | 14 | 30 | 20 | 1.5 | 45 | 110 | 0.9 |
8CR-EVM-VML3T | 3T | 39 | 19 | 64 | 13 | 30 | 20 | 1.5 | 38 | 102 | 0.8 |
8CR-EVM-VML1.5T | 1.5T | 33.5 | 17.5 | 80 | 12 | 28 | 16 | 1.5 | 35 | 85 | 0.4 |
8CR-EVM-VML1T | 1T | 27 | 15 | 4025 | 10 | 25 | 12 | 1.5 | 30 | 70 | 0.2 |
