CLGR® Galvanized Snatch Block with Hook for Manila Rope

Name: CLGR® Galvanized Snatch Block with Hook for Manila Rope
Brand: CLGR®

CLGR® Galvanized Snatch Block with Hook for Manila Rope boasts a higher Working Load Limit, making it a robust choice for demanding lifting applications.

The laser-cut sideplate is designed to open, facilitating easy rope insertion for efficient setup. It has the exclusive bolt-retaining spring, which prevents bolt loss, complemented by a secondary retaining pin for added security.

Its galvanized steel shell provides reliable corrosion resistance, ensuring durability in various environments, we usually use in Marine Operation.

To Get A Quote >

CLGR® Galvanized Snatch Block with Hook for Manila Rope Design

Overview of Galvanized Snatch Block with Hook for Manila Rope

Brand	CLGR®
Material	Steel
Surface Finished	Galvanized
Size	4″, 6″, 8″, 10″, 12″
Origin	China
Note	Do not exceed working load limit (WLL).

Specifications of Galvanized Snatch Block with Hook for Manila Rope

Part No.	Size	W.L.L	Dia of Rope	Net Weight
Part No.	in	lbs	in	kg
CRWHS104	4″	1200	3/4″	1.5
CRWHS106	6″	2400	7/8″	3.75
CRWHS108	8″	4800	1-1/8″	5.6
CRWHS110	10″	6600	1-1/4″	10.5
CRWHS112	12″	9600	1-1/2″	18
