CLGR® Galvanised Steel Trawl Block, also known as Trawl Try Net Block Galvanised and Fishing Trawl Blocks.
Try Net Blocks are essential components for commercial fishing vessels and trawlers, designed to guide cables or wires during the deployment and retrieval of fishing equipment.
Manufactured from the highest quality steel available, these trawl blocks feature a galvanized surface treatment that enhances their corrosion resistance, ensuring increased block life even in harsh saltwater environments.
These blocks are supplied with a pressure lubed fitting for a longer block life.
Whether in offshore, maritime, construction and commercial fishing, the CLGR® block can provide stable and reliable mechanical transmission support.
Brand | CLGR® |
Material | All steel construction |
Process | Hot dip galvanized; Flame hardened forged steel sheaves for wear resistance. |
Features | Double row, permanently sealed tapered roller bearings. |
Size | 4″, 6″, 8″, 12″, 16″, 22″ |
Part No. | Size (in) | W.L.L (ton) | Dia of Rope (mm) | Net Weight (kg) |
CRWTR04 | 4" | 2 | 16 | 5.2 |
CRWTR06 | 6" | 5 | 26 | 10.5 |
CRWTR08 | 8" | 10 | 36 | 28.5 |
CRWTR12 | 12" | 10 | 48 | 35 |
CRWTR16 | 16" | 20 | 50 | 60 |
CRWTR22 | 22" | 30 | 88 | 133 |
