CLGR® Eye and Eye Polyester Round Sling

Name: CLGR® Eye and Eye Polyester Round Sling
Brand: CLGR®

CLGR® Eye-to-Eye Polyester Round Slings are specifically engineered to excel in choker, vertical, and basket hitch applications, making them versatile for a wide range of lifting needs.

Crafted from high-quality polyester yarns and encased in a robust two-ply woven jacket, these slings are built to last. They exhibit remarkable resistance to abrasion, acids, UV rays, rot, and mildew, ensuring reliable performance even in challenging conditions. The flexible and lightweight nature of these slings not only makes them easy to rig and store but also allows for use without causing damage to painted or polished surfaces.

These slings come with a color-coding system that indicates their load capacity. They are also compliant with the stringent EN 1492-2 standards, guaranteeing their quality and safety. Available in a variety of sizes and strengths, they can be tailored to meet the specific requirements of different lifting tasks.

To Get A Quote >

Overview of CLGR® Eye and Eye Polyester Round Sling

Brand	CLGR®
Material	Constructed from a continuous loop of 100% polyester fiber
Sling Color	Yellow, Red, Blue, Orange, Violet (Purple), Brown, Gray, Green
WLL (Working Load Limit)	1ton/2ton/3ton/4ton/5ton/6ton/8ton/10ton/12ton/15ton/20ton/25ton/30ton/36ton/50ton
Safety factor	5:1, 6:1, 7:1, 8:1
Country of Origin	China

Specifications of CLGR® Eye and Eye Polyester Round Sling

Part No.	WLL (T)	Width (mm)	Color	WLL in ton with 1 webbing sling					WLL in ton with 2 webbing sling
				Straight lift	Choked Lift	Basket 0-7°	7-45°	45-60°	Straight Lift up to 45°	Straight Lift up to 45-60°	Choked Lift up to 45°
				1.0	0.8	2	1.4	1.0	1.4	1.0	1.12
CRRSEEP01	1	18	Voilet	1	0.8	2	1.4	1	1.4	1	1.12
CRRSEEP02	2	20	Green	2	1.6	4	2.8	2	2.8	2	2.24
CRRSEEP03	3	22	Yellow	3	2.4	6	4.2	3	4.2	3	3.36
CRRSEEP04	4	25	Gray	4	3.2	8	5.6	4	5.6	4	4.48
CRRSEEP05	5	27	Red	5	5	10	7	5	7	5	5.60
CRRSEEP06	6	32	Brown	6	6	12	8.4	6	8.4	6	6.72
CRRSEEP08	8	38	Blue	8	8	16	11.2	8	11.2	8	8.96
CRRSEEP10	10	45	Orange	10	10	12	14	10	14	10	11.2
CRRSEEP12	12	60	Orange	12	12	24	16.8	12	16.8	12	13.44
CRRSEEP15	15	70	Orange	15	12	30	21	15	21	15	16.8
CRRSEEP20	20	80	Orange	20	16	40	28	20	28	20	22.4
CRRSEEP25	25	90	Orange	25	20	50	35	25	35	25	28
CRRSEEP30	30	100	Orange	30	24	60	42	30	42	30	33.6
CRRSEEP36	36	115	Orange	36	28.8	72	50.4	36	50.4	36	40.32
CRRSEEP40	40	125	Orange	40	32	80	56	40	56	40	44.8
CRRSEEP50	50	180	Orange	50	40	10	70	50	70	50	56
CRRSEEP75	75	200	Orange	75	60	150	105	75	300	75	84
CRRSEEP100	100	250	Orange	100	80	200	140	100	400	100	112
