CLGR® Stainless steel Square Swivel Pad Eye

Name: CLGR® Stainless steel Square Swivel Pad Eye
Brand: CLGR®

CLGR® Stainless steel Square Swivel Pad Eye, also known as Swivel Eye Square Pad.

The Stainless Swivel Pad Eye delivers smooth 360-degree rotation for versatile rigging and mounting options.

Made from grade 304 or 316 stainless steel, it offers excellent corrosion resistance and long-term durability. It makes them ideal for long-term use in harsh or aesthetic environments.

Widely used in marine, architectural, and industrial applications, they provide secure connections and tension adjustment for lifting, sailing, and decorative structures.

Stainless Rigging Hardware includes shackles, turnbuckles, snap hooks, eye bolts, thimbles, and wire rope clips made from stainless steel grades such as AISI 304 and 316.

To Get A Quote >

clgr stainless steel square swivel pad eye

Overview of Stainless steel Square Swivel Pad Eye

Brand	CLGR®
Material	Stainless steel (AISI 304 / AISI316)
Processing	Stamping / Machining / Welding
Finish	Highly-Polishing
Size	5mm, 6mm, 8mm
Country of Origin	China

Specification of Stainless steel Square Swivel Pad Eye

drawing-of-stainless-steel-square-swivel-pad-eye-china-supplier

Part No.	D	A	Φ	H	WT
Part No.	mm				kgs
CRSSSSPE05	5	35	15	3	0.035
CRSSSSPE06	6	40	18	3	0.077
CRSSSSPE08	8	50	19	3	0.148

CLGR® Are Expecting Your Inquiry!

We design, manufacture and distribute products and provide services for lifting and material handling applications, the construction metal industry, the trawl industry and the yacht accessories industry.
