CLGR® Stainless Steel Diamond Pad Eye

Name: CLGR® Stainless Steel Diamond Pad Eye
Brand: CLGR®

CLGR® Stainless Steel Diamond Pad Eye, also known as Stamped Diamond Pad Eyes, Diamond Pad Eye Mounting Hoop.

Diamond Pad Eyes are versatile attachment points for shade sails, marine rigging, and construction applications. They are available in 304 or 316 grade stainless steel, offering excellent corrosion resistance and long-lasting durability.

Designed for secure mounting on various surfaces, each pad eye features 4 countersunk screw holes for a neat, flush finish. The polished surface adds an extra layer of corrosion protection for outdoor use.

Available sizes: 5mm, 6mm, 8mm, 10mm, 12mm. Larger sizes available on request.

Important: For maximum load distribution, we recommend using a heavy-duty backplate (sold separately) when installing on softer surfaces.

Please refer to the table below for detailed dimensions per size.

To Get A Quote >

clgr® stainless steel diamond pad eye china supplier

Overview of CLGR® Stainless Steel Diamond Pad Eye

Brand	CLGR®
Material	Stainless steel (AISI 304 / AISI316)
Processing	Stamping / Machining / Welding
Finish	Highly-Polishing
Size	5mm, 6mm, 8mm, 10mm, 12mm
Country of Origin	China

Specifications of CLGR® Stainless Steel Diamond Pad Eye

drawing-clgr®-stainless-steel-diamond-pad-eye-china-supplier

Part No.	D	A	B	H	h	w	d	WT
Part No.	mm							kgs
CRSSDEP05	5	36	60	23	15	16	4.5	0.031
CRSSDEP06	6	40	65	26	17	17	4.5	0.043
CRSSDEP08	8	50	80	32	21	21	6.2	0.077
CRSSDEP10	10	60	100	36	26	26	6.2	0.136
CRSSDEP12	12	80	120	50	38	32	6.5	0.251
